5 . パーツカメラ P a r t s c a m e r a ( C G G C ) 5 - 1 5 . パーツカメラ( C G G C ) 5 . P a r t s c a m e r a ( C G G C ) QP-132E P ARTS LIST ver07 x 4 . 5 1 2 3 3 4 4 5 6 4 6 7 9 1 1 2 3 1 2 1 3 3 2 1 5 1 6 3 0 1 7 2 4 2 5 2 3 2 3…
4.モジュール Y軸 Module Y axis(CGPY)
QP-132E PARTS LIST ver07
4-3
4.モジュール Y軸(CGPY)
4.Module Y axis(CGPY)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
60K5184T SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2.5X25L
61K1152H 32 GASKET ｶﾞｽｹｯﾄ DXT170-29-1
62Y3049Z 32 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL04-M5
63Y30557 48 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH04-01S
64Y3040F 16 UNION ﾕﾆｵﾝ KQN04-01S
65H10248 16 VALVE, PRESSURE REDUCING ﾊﾞﾙﾌﾞ 減圧 PR100
66CGPY0521 16 SHEET, RUBBER ｼｰﾄｺﾞﾑ
67K5357H
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X5L
68CGPY0900 15 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管
69CGPY0911 16 TUBE ﾁｭｰﾌﾞ
70CGPY0921 32 TUBE ﾁｭｰﾌﾞ
71CGPY0931 32 TUBE ﾁｭｰﾌﾞ
72Y30404 16 UNION ﾕﾆｵﾝ KQT04-00
73Y3053A 16 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQL08-01S
74Y3057E 48 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQH08-01S
75Y3065A 32 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQVD06-01S
76. 16 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ AKH04-00
77K5262H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M6X20L
78W1045A
WASHER, FLAT
ﾜｯｼｬ 平
4W-6
82A8362CGPY0940 1 TERMINAL, PIPING ﾀｰﾐﾅﾙ 配管 ･
5.パーツカメラ Parts camera(CGGC)
5-1
5.パーツカメラ(CGGC)
5.Parts camera(CGGC)
QP-132E PARTS LIST ver07
x4.5
1
2
3
34
4
5
6
46
7
9
11
23
12
13
32
15
16
30
17
24
25
23
23
17
24
17
24
17
24
19
24
14
27
20
27
20
18
21
44
35
21
44
35
21
44
21
44
47
23
37
28
29
23
36
35
21
44
40
33
22
41
42
43
21
45
22
33
22
26
5.パーツカメラ Parts camera(CGGC)
QP-132E PARTS LIST ver07
5-2
5.パーツカメラ(CGGC)
5.Parts camera(CGGC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1CGGC0014 1 BKT, SENSOR BKT ｾﾝｻ
2CGGC0020 16 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
3CGGC0033 16 BKT BKT
4CGGC0042 16 PLATE ﾌﾟﾚｰﾄ
5CGGC0055 16 BKT, SUPPORT BKT 支え
6CGGC0062 16 PLATE, SUPPORT ﾌﾟﾚｰﾄ 支え
7CGGC0130 16 BOX BOX
9CGGC0092 2 BKT, SENSOR BKT ｾﾝｻ
11CGGC0120 16 PIN, ECCENTRIC ﾋﾟﾝ 偏心
12H5120N 16
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
MSB6.5-20
13PPB1120 16 BLOCK ﾌﾞﾛｯｸ
14R4031G 4 RAIL ﾚｰﾙ PFP50N
15K1133A 16 CAMERA, CCD ｶﾒﾗ CCD IK-541
16R4023X 16 LENS ﾚﾝｽﾞ FTE0040X-A
17S4027S 40 SENSOR ｾﾝｻ V600-HS61
18A1062Z 40 AMPLIFIER, SENSOR ｱﾝﾌﾟ ｾﾝｻ V600-HA51 5m
19ACGGC8010 5 SENSOR ｾﾝｻ
20R1031S 16 LAMP, UV ﾗﾝﾌﾟ UV MFLZ-W4000C
21W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
22W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
23W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
24W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3
25W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
26W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
27K5224A SCREW, C/R PAN 小ﾈｼﾞ 丸 M3X6L
28N1082A NUT, HEX
ﾅｯﾄ 六角
M5P=0.8
29H5179A BOLT, HEX ﾎﾞﾙﾄ 六角 M5X40Lｾﾞﾝﾈｼﾞ
30H5265A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2X5L
32H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L
33H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
34H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
35H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
36H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L
37H5303A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X22L
40H5278A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X25L
41K2008A 16 CAP ｷｬｯﾌﾟ BNC-BR1
42K2001T 16 CAP ｷｬｯﾌﾟ HR10-7R-C
43W1020A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M
44H5277A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12L
45CGGC0100 8 BKT, COVER BKT ｶﾊﾞｰ
46W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
47R5025T 32 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ 5ﾟX10 ･
