2 0 . P F U - 1 E ( C G U F ) QP-132E P ARTS LIST ver07 2 0 - 4 2 0 . P F U - 1 E ( C G U F ) 番号 図番 & ｺ ｰ ﾄ ﾞ 番号 個数 品名 規格 備考 N o . D r g . N o . & C o d e N o . Q T Y D e s c r i p t i o n R a t i n g R e m a r k…

100%1 / 129
20.PFU-1E(CGUF)
QP-132E PARTS LIST ver07
20-3
20.PFU-1E(CGUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
84H5306A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X35L
86H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L
87H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X40L
88W1027A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M
89. SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M5X12L
90N1077H NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 3ｼｭ
93CGUF0376 1 COVER ｶﾊﾞｰ
94CGUF0381 1 COVER ｶﾊﾞｰ
95CGUF0391 2 HOLDER 受け
96CGUF0401 2 HOLDER 受け
97CGUF0411 2 BKT BKT
98CGUF0420 2 PIN, LOCATING ﾋﾟﾝ 位置決め
9987728CGUF1593 1 COVER ｶﾊﾞｰ
101CGUF0480 2 JAW 爪
102CGUF0490 2 BLOCK ﾌﾞﾛｯｸ
104CGUF0520 4 SEAL ｼｰﾙ
105CGUF0530 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ
106CGUF0541 2 JOINT ｼﾞｮｲﾝﾄ
10787728CGUF1515 1 BASE ﾍﾞｰｽ
109CGUF0572 1 COVER ｶﾊﾞｰ
11587728CGUF2490 1 DUCT ﾀﾞｸﾄ
11687728CGUF1611 1 STAND ｽﾀﾝﾄﾞ
11787728CGUF1633 1 PLATE ﾌﾟﾚｰﾄ
118Y9205CPUF1361 1 PLATE ﾌﾟﾚｰﾄ
123CGUF0730 2 BLOCK ﾌﾞﾛｯｸ
124CGUF0740 1 BKT, SENSOR BKT ｾﾝｻ
125CGUF0750 1 BKT, SENSOR BKT ｾﾝｻ
126K51711 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M5X6L
128K5170T SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6L
129N1104A NUT, HEX ﾅｯﾄ 六角 M20 P=2.5
130H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X12L
131K5171L SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M4X6L
132H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M4X20L
133H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M6X15L
134H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M6X20L
137H3051C 2 COVER ｶﾊﾞｰ B-214
144H5281A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M3X25L
145S31145 2 SW, PROXIMATE SW 近接 APM-D3A1-03
146K5201E SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M2.6X6L
14787728CGUF1544 4 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け
14887728CGUF1552 1 CATCH PAN 受け皿
14987729CGUF1622 1 GUIDE ｶﾞｲﾄﾞ
15087728CGUF1643 4 GUIDE ｶﾞｲﾄﾞ
15187728CGUF1662 1 PLATE ﾌﾟﾚｰﾄ
20.PFU-1E(CGUF)
QP-132E PARTS LIST ver07
20-4
20.PFU-1E(CGUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
15287728CGUF1671 1 COVER ｶﾊﾞｰ
15387728CGUF1683 1 PLATE ﾌﾟﾚｰﾄ
15487728CGUF1691 4 GUIDE ｶﾞｲﾄﾞ
15587728CGUF1704 3 HOLDER ﾎﾙﾀﾞ
15687728CGUF1721 2 BKT BKT
15787728CGUF1860 1 COVER ｶﾊﾞｰ
15887728CGUF1741 1 GUIDE ｶﾞｲﾄﾞ
15987728CGUF1750 1 BKT BKT
16087728CGUF1760 1 BKT BKT
16187728CGUF1770 1 STOPPER ｽﾄｯﾊﾟ
16287728CGUF1782 1 GUIDE ｶﾞｲﾄﾞ
16387728CGUF1791 1 GUIDE ｶﾞｲﾄﾞ
16487728CGUF1820 1 COVER ｶﾊﾞｰ
16587728CGUF1840 1 SEAL ｼｰﾙ
166Y9205CPUF1185 1 BKT BKT
167Y9205CPUF1200 8 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め
168Y9205CPUF1251 12 COLLAR ｶﾗｰ
169Y9205CPUF1260 12 PIN, BACKUP ﾋﾟﾝﾊﾞｯｸｱｯﾌﾟ
170Y9205CPUF1270 4 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え
171Y9205CPUF1281 2 COLLAR ｶﾗｰ
172Y9205CPUF1391 1 GUIDE ｶﾞｲﾄﾞ
173Y9205CPUF1401 1 GUIDE ｶﾞｲﾄﾞ
175WSD0013 24 CLAMPER ｶﾗｰ
176WSD0641 24 BOLT ﾎﾞﾙﾄ
177WDS0651 24 SPRING ｽﾌﾟﾘﾝｸﾞ
178H4435T 24 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｱ L-1150ZZ
179R5025T 24 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ 5ﾟX10
180H2049A 2 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 3ﾟX12
181Y9205CPUF2330 1 BKT, SUPPORT BKT ｽﾄｯﾊﾟ
182Y9205CPUF2320 1 BKT, SUPPORT BKT ｽﾄｯﾊﾟ
183H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
184H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L
185H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
186K5172Z SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M6X10L
187K5171R SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M4X8L
188K5171L SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M4X6L
189W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L
190Y9205CPUF1460 1 BKT BKT
191Y9205CPUF1470 1 BKT BKT
19287728CGUF1871 1 BKT BKT
19387728CGUF1881 1 BKT BKT
19487728CGUF2010 1 BKT BKT ･
