Machine Specifications

Edition 2.0E - 12 - NXT II Specifications

Less than 14

X

Y

Less than 18

3.4. Head Specifications

Items H12HS[H12S] H08 H04

No. of nozzles 12 8 4

Part size

(0402)

Note 5

0603 ~

5 × 5 mm

(6 nozzle operation is 5 x 5

mm to 7.5 x 7.5 mm)

(0402)

Note 5

0603 ~

7.5 × 7.5 mm

(4 nozzle operation is 7.5 x

7.5 mm to 12 x 12 mm)

1608 (0603) ~ 38 x 38

Note 1

Max. part height 3 mm 6.5 mm 9.5 mm

Max. premounted part height

(upper surface)

3 mm 6.5 mm 9.5 mm

Packaging Tape Tape

Tape, Trays

Note 4

,

Sticks

Cpk≥1.00

±0.050 ±0.050 ±0.050

Placing accuracy

Note 2

(Rectangular chips and

small odd-form parts)

Cpk≥1.33

±0.066 ±0.066 ±0.066

M3II 22500 [18000] 11000 6500

M6II 22500 [18000] 11000 6500

Throughput

Note 3

(cph (chips/hr))

M6IISP 18500 [17000] 10000 6000

Nozzle change Yes Yes Yes

Notes:

1. 4 nozzle spec.: Max. 13 × 13 mm

2+2 nozzle spec.: Max. 14 x 14 mm

(or corner to corner dimensions of

19.8 mm or less and 14 mm or less

in the Y-direction) + 11 x 11 mm

2 nozzle spec.: Max. 18 x 18 mm

(or corner to corner dimensions of 26 mm or less and 18 mm or less in the Y-direction)

1 nozzle spec: Max. 38 × 38 mm

Parts for feeders and trays should be supplied in the XY-direction as shown in the diagram below.

2. The placing accuracy above is based on tests conducted at Fuji.

3. The throughput above is based on tests conducted at Fuji.

4. When using tray unit-L, parts less than 9 mm from the lower surface of the tray to the upper surface of the

parts are not supported. However, trays up to 29.5 mm in height (thickness) are supported.

5. The following conditions are required when placing 0402(01005) parts.

a. Manual offsetting using PAM is recommended when the required placement accuracy is 0.05 mm or

less.

b. Changes to Fuji Flexa nozzle spec data are required.

c. 0402 (01005) compatible feeders are required.

Machine Specifications

Edition 2.0E - 13 - NXT II Specifications

Items H12HS[H12S] H08 H04

Part size

~1.9 x

1.9

~2.8 x

2.8

~5 x 5

~2.4 x

2.4

~3.6x

3.6

~6.5x

6.5

~7.5

x 7.5

~9 x 9

~14 x

14

~26 x

26

~32 x

32

Min. pitch

(mm)

0.4 0.5 0.65 0.4 0.5 0.65 0.9

0.4 0.5 0.65 0.9

Min.

width/dia.

(mm)

0.17 0.2 0.3 0.17 0.2 0.3 0.4

0.17 0.2 0.3 0.4

Lead parts

Note 6

(Part size

includes leads)

Min. spacing

(mm)

0.23 0.3 0.35 0.23 0.3 0.35 0.5

0.23 0.3 0.35 0.5

Part size

~2.7 x

2.7

~3.8 x

3.8

~5 x 5

~3.4 x

3.4

~4.8

x 4.8

~7.5

x 7.5

~13 x

13

~19x 19

~32 x

32

Min. pitch

(mm)

0.5 0.65 0.5 0.5 0.65 1.0

0.5 0.65 1.0

Min.

width/dia.

(mm)

0.25 0.3 0.5 0.25 0.3 0.5

0.25 0.3 0.5

Bump parts

Note 6

Min. spacing

Between

bumps (mm)

0.25 0.35 0.5 0.25 0.35 0.5

0.25 0.35 0.5

6. The Bump parts specifications for H12S [H12], H08, and H04 heads, and the lead parts specifications for

H12S[H12]/H08/H04 heads will differ based on the part size. (Using the conditions for manual offsets based

on theoretical PAM.)

Items G04 H02 H01

No. of nozzles 4 2 1

Part size

0402 ~ 15 x 15

mm

Note 12

1608 ~ 74 × 74

mm

Note 9

(32 ×

180)

1608 ~ 74 × 74

mm (32 × 180)

Max. part height 6.5 mm 25.4 mm

Note 10

25.4 mm

Max. premounted part height (upper

surface)

6.5 mm 25.4 mm

Note 10

25.4 mm

Packaging

Tape, Trays,

Sticks

Tape, Trays,

Sticks

Tape, Trays,

Sticks

M3II, M6II

±0.030 ±0.030

± 0.030

± 0.050

Note 11

Cpk

≥

1.00

M6IISP

±0.018 ±0.018 ±0.018

M3II, M6II

±0.040 ±0.040

± 0.040

± 0.066

Note 11

Placing

accuracy

Note 7

(parts with leads)

Cpk

≥

1.33

M6IISP

±0.024 ±0.024 ±0.024

M3II 6800 5600 4200

M6II 6800 5600 4200

Throughput

Note 8

(cph

(chips/hr))

M6IISP 6200 4700 3500

Nozzle change Yes Yes Yes

Machine Specifications

Edition 2.0E - 14 - NXT II Specifications

Lead parts

Bump parts

Depends on the part camera specification.

Refer to”4.5 Parts Camera Unit”.

7. The placing accuracy above is based on tests conducted at Fuji.

8. The throughput above is based on tests conducted at Fuji.

9. The supported part sizes for 2 nozzle operation are 1608 to 28 x 28 (or parts with a diagonal length of 40 mm

or less).

10. Short nozzles are required for parts with a height of 17.4 mm < H 25.4 mm. For parts that are using a

mechanical chuck, short mechanical chucks are required for parts with a height of 21.5 mm < H 25.4 mm.

Also, for parts with a part height 15.5 mm < h 21.5 mm, there are cases when a short mechanical chuck is

required, so refer to your Fuji representative before proceeding.

11. This is the specification for when using the sidelight camera. If the manual offset values for the placing

accuracy measurement results are entered the placing accuracy for that nozzle becomes 0.030 mm (Cpk

1.00).

12. When acquiring a batch image of 4 parts, the part size can be up to 13 x 13 mm.
