Standard Functionality
Edition 2.0E - 34 - NXT II Specifications
6.5. HBC Function
This is a function of the M6IISP.
This function places the jig part in the jig stand, measures the placement error
amount, and adds the result to the placement correction measurement. When
combined with auto calibration, highly accurate placement is possible.
As well as the nozzle jigs for auto calibration, a separate nozzle jig for the HBC
function is required.
6.6. Placing Pressure Control
This function is used to control the force applied to parts and is available only for
the H01, and H02 heads. (Control range: 2.2 to 9.8 N)
6.7. Pressure Insertion Control
This function is used to support parts that require placement using pressure
insertion. Only H01, H02 and OF heads can use this function.
Supported range: 39.2 to 98N (for H01, H02 and OF heads)
6.8. GCU (Glue Check Unit)
This unit is put on the device pallet and used together with the GL head.
The GL head dispenses glue dots on this unit and the machine measures needle
offset and the size of the dispensed glue.
Head No. of Required Nozzle Jigs
H12HS[H12S], H08 Φ1.3 1
H04 Φ5.0 1
G04 Φ1.3,Φ5.0 1 each
H01, H02 Φ1.3,Φ5.0 1 each
OF Φ5.0 1
Standard Functionality
Edition 2.0E - 35 - NXT II Specifications
6.9. Parts Present Check Function
The part presence check function is used to detect the presence of a part on the
nozzle tip.
This function is available for the H01, H02 and G04 heads.
The limitations that apply to this function are shown in the table below.
Furthermore, this function does not affect throughput.
Item H02 H01
G04
(Fiber sensor
model)
Before
placement
O O O
After placement O O O
Before dip O O O
Part presence
check function
After dip O O O
Applicable parts
Parts that do not leak air at
pick-up
Minimum part height
of 0.5 mm
Applicable nozzles
All nozzles other than
mechanical chucks or
MELF nozzles.
No limitations
Options
Edition 2.0E - 36 - NXT II Specifications
7. Options
7.1. Options
Item/Type Remarks Class
Standard reel
holder use
Feeder loading pallet C C
Device
pallet
Pallet with
bucket
Feeder loading pallet
Remove the feeder reel holder and attach
the bucket type reel holder to the device pallet.
C
Reel set stand
Used to secure feeders when setting part reels.
2 feeders can be set simultaneously.
There are two types of reel set stands, ones for feeders
with reel holders and ones for feeders without reel
holders (feeder pallets have buckets).
In addition, there is a Kitting option available for the reel
set stand.
Kitting option: This function deletes the feeder-reel
relationship registered in Fujitrax when the feeder is set
in the stand.
C
M3II Device Pallet Change Unit for use with M3II modules. C
Standard
reel holder
use
M6II,
M6IISP
Device Pallet Change Unit for use with M6II, M6IISP
modules.
C
M3II M3II module Pallet Change Unit for pallets with bucket. C
PCU
Pallets
with
bucket
M6II,
M6IISP
M6II, M6IISP module Pallet Change Unit for pallets with
bucket.
C
MCU
Module Change Unit (Used with M3/M6/M6IISP
modules.)
C
Nozzle Spare nozzles C
L Part size: up to 74 × 180 × 25.4 mm (7 slots) C
M Part size: up to 45 × 180 × 13 mm (5 slots) C
Reject parts
conveyor
M
Long type
This unit is required when setting 2 tray unit-Ms on the
device pallet.
Part size: up to 45 × 180 × 13 mm (5 slots)
C
Waste tape processing unit Waste tape stored in waste tape collection box. AorB
Loading and removal of feeders possible during
production. Tape feeders also support splicing.
W4P1-7”
W8-7”
W8-13”
W12-7”
W12-15”
W16-15”
W24-15”
W32-15”
W44-15”
W56-15”
W72-15”
W88-15”
Type without
reel holder
also available.
Feeders
W4/8: P1/P2/P4 variable W12~: P4xn variable
C
