Options  Edition 2.0E - 38 - NXT II S pecifications Tray drawer stand Stand used to store tray drawers. (Max.: 21) C Tray unit-M (M6(S), M6II, M6IISP module) Mounted on device pallet. Max. 2 units/stage. Slot qty.: 20 D…

100%1 / 53
Options
Edition 2.0E - 37 - NXT II Specifications
Stick Feeders
4 types: 1S, 1L, 2S, 2L
The type will differ based on the part width and length
(Refer to “3.1 Machine Specifications”). It may be
necessary to specially manufacture types 1L and 2L to
match the part on a case by case basis.
C
Vibratory Stick Feeders
This feeder supplies parts from a stick using a vibratory
action. (Required slots: 5)
C
Feeder stand
Storage rack for tape and stick feeders.
Max. capacity: 45 × 2 rows
C
Feeder stand (Pallets with
bucket)
Storage rack for tape and stick feeders.
Max. capacity: 45 × 2 rows
C
Splicing jig Used for tape splicing C
Feeder with splicing sensor
Detects the spliced position on the tape to perform more
precise remaining parts administration. Available for W8
~ W88 mm feeders.
C
Feeder inspection jig
Able to check feeder pickup position and pickup height.
Also able to upgrade feeder firmware version, to change
feeder serial number and to perform idling operation of
feeders.
W8 to 88 feeders are supported.
C
Roller conveyor Provides support for PCBs over 1.5 kg and up to 3 kg A
PCB back-up pin
Available in addition to those pins provided with the
machine. Positioning is performed manually.
AorB
Auto PCB back-up pins (Head)
A dedicated head function for automatically allocated
back-up pins.
AorC
Auto PCB back-up pins
(Conveyor)
A stocker for holding back-up pins is attached to the
conveyor.
AorB
Soft back-up pins
Back-up pins made of a soft material are used to
suppress shock during placement, and therefore reduce
PCB vibrations.
AorB
Support for thin PCBs
Provides support for PCBs under 0.4 mm in thickness
(min.: 0.3 mm)
A
Tray unit-L (M6(S), M6II,
M6IISP module)
Interchangeable with device pallet.
Drawer qty.: 20 (Max. 8 mm/drawer)
Max. tray thickness: 32 mm/drawer (6 drawers)
Size: 335 (W) × 330 (L) mm
2 trays may be loaded when tray size is 160 (W) × 330
(L) and under.
Refer to the “Device unit specifications manual” for
details.
C
Tray unit-LT (M6(S), M6II,
M6IISP module)
Interchangeable with device pallet.
2 magazines containing tray drawers may be loaded.
Drawer qty.: 12 x 2 (Max. 8 mm/drawer)
Max. tray thickness: 32 mm/drawer (4 drawers x 2)
Tray size: 276 (W) × 330 (L) mm
2 trays may be loaded when tray size is 135.9 (W) × 330
(L) and under.
Refer to the “Device unit specifications manual” for
details.
C
Tray drawer
Drawer for the tray unit-L.
Set the parts tray in the tray drawer and load the drawer
into the tray unit-L.
C
Options
Edition 2.0E - 38 - NXT II Specifications
Tray drawer stand Stand used to store tray drawers. (Max.: 21) C
Tray unit-M (M6(S), M6II,
M6IISP module)
Mounted on device pallet.
Max. 2 units/stage. Slot qty.: 20
Drawer qty.: 10 (1 tray/drawer)
Tray size: 135.9 (W) × 322.6(L) mm (JEDEC standard)
For more information, refer to the “Device Unit
Specifications Manual.”
C
Chip tray pallet for tray unit-M
A pallet which holds chip trays. One tray unit-M can hold
up to 10 pallets.
C
Head maintenance stand
Stand used to secure the head while performing
maintenance
C
PSU (Pallet Stand Unit)
Stand used to store the device pallet. There are 4 types.
• Stand for four M3II pallets
• Stand for two M6II, M6IISP pallets
• Stand for four M3II bucket-type pallets
• Stand for two M6II, M6IISP bucket-type pallets
Leveling sheet specification is standard. Optional caster
type is also available (more floor space is required than
standard type).
C
MSU (Module Stand Unit)
Stand used to hold spare modules.
2 M3II modules and 1 M6II, M6IISP module can be set.
C
Engineering panel stand
Stand for the computer with the engineering panel.
Casters are attached.
C
PCB ID (2D code) read
function using the
Fiducial mark camera
This function is used to read IDs (2D codes) on the PCB
surface with the fiducial mark camera.
This is a Fujitrax option and can be selected when using
Fujitrax Profiler.
B
DFU (Dip Flux Unit)
Unit used to apply flux to bumps of parts.
Loaded on the device pallet. Equipped with automatic
flux supply unit.
Select from two types; the bridge type (flux reservoir
slides back and forth) and rotary type (flux reservoir
rotates).
1. Bridge type
Occupies 9 slots
Thickness of the flux: 0.030 ~ 0.500 mm (adjustable)
Flux thickness shape: 45 x 45 (H01,H02 1 nozzle),
20 x 20 (H02 2 nozzles),
15 x 15 (G04)
2. Rotary type
Occupies 12 slots
Thickness of the flux: 0.03 ~ 0.150 mm
(adjustable)
Flux thickness shape: 45 x 45 (H01, H02 1 nozzle),
20 x 20 (H02 2 nozzles),
15 x 15 (G04)
C
Coplanarity sensor
This sensor checks the height of leads and bumps. It can
be installed onto a M6II, M6IISP module. Refer to the
“Coplanarity sensor specifications manual” for details.
A
Options
Edition 2.0E - 39 - NXT II Specifications
M
Tray feeder for chip trays.
Loaded on the M3II or M6II, M6IISP device pallet (11
slots required).
Adapter for 2" tray is attached to the unit as standard,
while those for 3" and 4" trays are optional.
Refer to the "Device unit specifications manual" for
details.
C
Tray feeder
L
Tray feeder for chip and JEDEC trays.
Loaded on the M6II, M6IISP device pallet (14 slots
required).
One JEDEC tray can be loaded on a tray feeder-L.
Adapters for chip trays (2", 3" and 4") are optional.
Refer to the "Device unit specifications manual" for
details.
C
Parts presence check function
This function checks for the presence of parts on the
nozzle tip before and after placement and is an optional
function for the head. Refer to "7.2 Parts Presence
Check Function" for details.
A
Tray unit-M change unit
This is used when removing a tray unit-M from a feeder
pallet.
It is possible to set one tray unit-M on a tray unit-M
change unit.
These are dedicated for NXT machines.
A: Installed during machine assembly
B: On-site option installation possible
C: Supported with purchase of individual unit
