NXT Related Software
Edition 2.0E - 44 - NXT II Specifications
<Top magazine priority mode production (tray unit-LT)>
With top magazine priority mode production, parts are supplied from the top of
the magazine. Based on the Fujitrax parts out warning, prepared parts are set at
the bottom of the magazine. When they are set, the attached ID reader inside
tray unit-LT reads the tray drawer automatically. By registering the tray drawer ID
and the tray parts combination in the Fujitrax system before production, the
number and type of tray parts can be confirmed, and the tray parts can be stored
in the desired slot at the bottom of the magazine.
In order to store used trays, empty slots (3 slots) must be specified at the top of
the machine.
< Free Feeder Allocation Function>
When using Fujitrax, it is possible to commence production even though the
parts allocation on certain modules differs from that set in the production
program.
As a result, provided that the parts required for that module are prepared in
advance, they can be freely allocated to any slot within the same module.
However, it is not possible to freely allocate parts to different modules.
Furthermore, it is not possible to use this function together with the above
dynamic alternate feeder function.
<Main Functions Enabled by Adopting Fujitrax>
• Incorrect part setting prevention function
• Parts out warning function
• PCB traceability data acquisition
• PCB ID (2D code) read function using the NXT fiducial mark camera
Note: Please refer to the “Fujitrax Specifications” for further details on Fujitrax specifications.
Module Configuration
Edition 2.0E - 45 - NXT II Specifications
Standard Units
Module
(
M3II
)
XY robot
(
M3II
)
Cover
(
M3II
)
Mark camera
High resolution camera
Standard camera
Parts camera
P03 camera
Re
j
ect
p
arts box
Configurable Units
Main conveyor
Double conveyor
Single conveyor
Roller conveyor
Thin PCB support conveyor
Device pallet
20 slot pallet
Head H12HS[H12S] H04
Nozzle station
For H12HS[H12S]/H08
For H04 (M3II)
For H01/H02 (M3II)
Backup plate
Standard backup pin /
Auto backup pin use
Double conveyor use
Single conveyor use
Standard cover
H08 H02
GL
GCU (Glue check unit)
H01
For G04 (M3II)
G04
Optional units
Waste tape processing unit Feeders Nozzles Reject parts conveyor
Auto back-up pins DFU (Dip flux unit)
Tray feeder-M
9. Module Configuration
9.1. Module Configuration
9.1.1. M3II Module Configuration
Module Configuration
Edition 2.0E - 46 - NXT II Specifications
Sidelight camera
Standard Units
Module
(
M6II
,
M6IISP
)
XY robot
(
M6II
,
M6IISP
)
Cover
(
M6II
,
M6IISP
)
Mark camera
High resolution camera
Standard camera
Parts camera
P03 camera
Tray unit-L
For H04 (M6II, M6IISP)
For H01/H02 (M6II, M6IISP)
For H04 (Tray unit-L/LT use)
For H01/H02 (Tray unit-L/LT use)
OF
For OF (M6II, M6IISP)
For OF (Tray unit-L/LT use) For OF (Tray unit-M x 2 use)
Tray unit-LM
Tray unit-LT
For G04 (M6II, M6IISP)
For G04 (Tray unit-L/LT use)
Configurable Units
Main conveyor
Double conveyor
Single conveyor
Roller conveyor
Thin PCB support conveyor
Device pallet
45 slot pallet
Head
H12HS[H12S] H04
Nozzle station
Backup plate
Standard backup pin /
Auto backup pin use
Double conveyor use
Single conveyor use
Standard cover
H08 H02
GL
GCU
(
Glue check unit
)
H01
G04
For H12HS[H12S]/H08
9.1.2. M6II, M6IISP Module Configuration
