Machine Data and Operatin g Environment Edition 2.0E - 8 - NXT II S pecifications Power Consumption Type Estimated maximum power c onsumption (kVA) M3II module 1.5 M6II module 1.5 M6IISP module 1.2 4MII base 1.0 2MII bas…

Machine Data and Operating Environment
Edition 2.0E - 7 - NXT II Specifications
2. Machine Data and Operating Environment
2.1. Machine Data and Operating Environment
Item Description
Power Requirement
*1
200 ~ 230V AC (± 10%), three-phase (50/60Hz)
Air Pressure
*2
0.5 MPa (ANR)
Air Consumption
40 L/min. (ANR) (4MII base machine)
20 L/min. (ANR) (2MII base machine)
+ 100 L/min. (ANR) (when using remover)
+ 35 L/min. (ANR) (when using a GL head)
Dimensions
740.2 mm (2M base)/1,390.2 mm (4M base),
Width: 1,934 mm
Height: 1,476 mm
Weight
4MII base: 715 kg
2MII base: 385 kg
M3II module: 355 kg (double conveyor specification)
M6II module: 520 kg (double conveyor specification)
M6IISP module: 525 kg (double conveyor specification)
Tray unit-LT: 173.7 kg (including 8 pallets and magnets, no remover)
Tray unit-L: 150 kg (including 7 pallets and magnets, no remover)
Tray unit-M: 37 kg
Display Panels
Monitor: Toggle between operation and image monitor
Display: Illustration based operation
Machine Color
*3
Module cover: Silver
Module body: White
Base: Grey, white
Installation Environment
*4
Temperature:15° ~ 35°C
Humidity:30% ~ 80% RH
Elevation:1000 m or under
Supported Safety Standards IP22 or equivalent
*5
, UL standard, CE marking
Notes:
1. Power source: 200 ~ 230V AC (± 10%), three-phase (For more details, refer to “Cautions when installing
NXTII” below).
2. Atmospheric dew point: -17 degrees Celsius or less, Particle size: 5 m or less, Max. oil vapor content: 5
mg/m³ or less. An air source is required when installing the NXTII.
3. The color of the machine cannot be changed.
4. Humidity should be free of condensation. Recommended installation environment --- temperature; 15 ~ 30
degrees Celsius, humidity; 50 ~ 70 %
5. IP22: IEC standardized protection against intrusion by body parts and water.

Machine Data and Operating Environment
Edition 2.0E - 8 - NXT II Specifications
Power Consumption
Type
Estimated maximum power consumption (kVA)
M3II module 1.5
M6II module 1.5
M6IISP module 1.2
4MII base 1.0
2MII base 1.0
Tray unit-L 0.1
Tray unit-LT 0.5
Note: Values change depending on the conditions used.
* Cautions when installing NXTII
The following cautions should be observed when installing the NXTII:
1. A dedicated power source, not shared with other large equipment, should be
used in order to avoid problems with electrical noise, voltage fluctuations,
high-frequency distortions, and other related problems.
2. There is leakage current of approximately 30 mA per one NXTII machine
(one 4MII base with 4 M3II modules). It may be required to consider the
limitation for the number of machines that are connected to a breaker when
using leak detectors. It is also required to install an isolating transformer to
the machine when needed to avoid this electric leakage. The user must
prepare the isolating transformer.
3. When using a short circuit breaker, ensure to use a high-speed model with
sensed current of 100 mA. Use one short circuit breaker for up to two 4MII
bases.
Recommended isolating transformer specifications
Items
Specifications
Phase
Three phase
Frequency
50/60Hz
Primary-side voltage
(input)
Depends on customer’s power supply devices
Secondary-side voltage
(output)
200V±10%
Power consumption Refer to the previous “Power Consumption” item
Note
Must be isolating transformer
Installation location Location in the vicinity of the machine (base) recommended

Machine Specifications
Edition 2.0E - 9 - NXT II Specifications
3. Machine Specifications
3.1. Machine Specifications
Items Specification
Part size (0402
Note 2
) 0603 ~ 74 × 74 mm (32 × 180 mm)
Parts
Note 1
Max. part height Max 25.4 mm
Chip and small
odd-form parts
±0.050 mm Cpk ≥1.00, ±0.066 mm Cpk ≥1.33
M3II, M6II ±0.030 mm Cpk ≥1.00, ±0.040 mm Cpk ≥1.33
Placing
accuracy
Note 3
Leaded parts
M6IISP ±0.018 mm Cpk ≥1.00, ±0.024 mm Cpk ≥1.33
Pick-up rate
Note 4
99.95% (not including automatic recovery)
Tape size
JEITA (formerly EIAJ), JIS standard tape parts
Concerning 8 mm tape with 7 inch reels, the reel width should be
14.0 mm or less.
8 mm tape: 13 inch reels or smaller
12 ~ 88 mm tape: 15 inch reels or smaller
Note: Please refer to “Device Unit Specifications Manual” for detailed
specifications.
Stick
Type S 4.5 ≤ part length ≤ 60 mm
Type L 60 ≤ part length ≤ 180 mm
Type 1 4 ≤ part width ≤ 15 mm (6 ≤ stick width ≤ 18 mm)
Type 2 15 ≤ part width ≤ 32 mm (18 ≤ stick width ≤ 36 mm)
Note: There are 4 types of stick feeders: 1S, 2S, 1L and 2L.
Note: Please refer to “Device Unit Specifications Manual” for detailed
specifications.
Tray size
Tray unit-L 335(W) x 330(L) mm (When 1 tray loaded)
160(W) x 330(L) mm (When 2 trays loaded)
Tray unit-LT 276(W) x 330(L) mm (When 1 tray loaded)
135.9(W) x 330(L) mm (When 2 trays loaded)
Tray unit-M 135.9(W) x 322.6(L) mm (JEDEC standard)
Note: Please refer to “Device Unit Specifications Manual” for detailed
specifications.
Packaging
Other
JIS, JEITA (formerly EIAJ) standard tape parts, stick parts, tray parts,
etc. (Parts supported by EIA standard also supported by JEITA
(formerly EIAJ)
Fiducial mark reading time
Note 5
Approximately 0.25 sec./mark
Notes:
1. Limitations apply based on the placing head used.
2. The following conditions are required when placing 0402 (01005) parts.
a. Manual offsetting using PAM is recommended when the required placement accuracy is ±0.05 mm or
less.
b. Changes to Fuji Flexa nozzle spec data are required.
c. 0402 (01005) compatible feeders are required.
