Machine Structure
Edition 2.0E - 27 - NXT II Specifications
4.9. Device Pallet and Occupied Slots
4.9.1. Feeder Pallet
This highly flexible feeder loading unit supports batch replacement using a
dedicated device pallet change unit.
Pallet sizes differ depending on the module size used.
A waste tape box is fitted below the device pallet mounting area.
Feeder replacement is possible even during PCB production.
Feeder Type Slots Required
M3II Feeder
Capacity
M6II Feeder
Capacity
M6IISP Feeder
Capacity
W8 7" reel 1 20 45 44
W8 13" reel 2 10 23 22
W12 2 9 22 22
W16 3 6 15 15
W24 3 6 15 15
W32 4 5 11 11
W44 5 4 9 9
W56 6 3 7 7
W72 7 2 6 6
W88 9 2 5 5
1S 2 9 22 22
1L 2 9 22 22
2S 4 4 11 11
Single Stick
Feeder
2L 4 4 11 11
Note:
M: Reject parts conveyor-M, L: Reject parts conveyor-L
1S/1L/2S/2L: Stick feeder type 1S/1L/2S/2L, GCU: Glue check unit
Note: This table represents a view of the feeders from the operator’s side. "X” in the table means that the feeder
type cannot be loaded. The number of slots and pitch required for W4P1 feeders is the same as for W8-7”
feeders.
Left Side
(
Pitch
)
Ri
g
ht Side
Ref.
Machine Structure
Edition 2.0E - 28 - NXT II Specifications
4.10. Feeder Pallet with Attached Bucket
A pallet with attached bucket to enable W8 13-inch feeders to be loaded in one
pitch can now be selected as an option. The feeder reel holder is removed, and
in its place, the pallet with bucket is set on the machine. A dedicated feeder
pallet change unit (PCU) is required for pallets with buckets. A custom half
bucket is required when Tray unit-M is used alongside a pallet (M6II, M6IISP)
with an attached bucket.
Feeder Type
Occupied
Feeder slots
Occupied
Bucket slots
M3II Feeder
Capacity
M6II Feeder
Capacity
M6IISP Feeder
Capacity
W8 1 1 20 45 44
W12 2 2 9 22 22
W16 2 2 9 22 22
W24 3 2 6 15 15
W32 4 3 5 11 11
W44 5 4 4 9 9
W56 6 5 3 7 7
W72 7 6 2 6 6
W88 9 7 2 5 5
Single Stick Feeder 1S 2 9 22
1L 2 9 22 22
2S 4 4 11 22
2L 4 4 11 11
Note: M: Reject parts conveyor-M, L: Reject parts conveyor-L
1S/1L/2S/2L: Stick feeder type 1S/1L/2S/2L, GCU: Glue check unit
Note: This table represents a view of the feeders from the operator’s side. "X” in the table means that the feeder
type cannot be loaded. The number of slots and pitch required for W4P1 feeders is the same as for W8
feeders.
Left Side (Pitch)
Ref.
Right Side (Pitch)
Machine Structure
Edition 2.0E - 29 - NXT II Specifications
4.11. Loading Feeders at the Ends of a Pallet
Slot No.
Feeder
1 2 3 4 5 … 14 …
16
(41)
17
(42)
18
(43)
19
(44)
20
(45)
W8 O O O O O
O O O O
O
*1
W12 × O O O O
O O O O
×
W16 × O O O O
O O O O
×
W24 × O O O O
O O O O
×
W32 × × O O O
O O O O
×
W44 × × O O O O O O × ×
W56 × × × O O
O O O
× ×
W72 × × × O O O O × × ×
W88 × × × × O O × × × ×
Type1 × O O O O O
O O O
×
Single
Stick
Feeder
Type2 × × O O O
… … …
O O O × ×
GCU × × × × × … O … × × × × ×
Note:
Numbers in brackets in the “Slot #” row represent slot numbers for M6II, M6IISP modules.
Checks in the table indicate the slot numbers that each feeder can be set on.
Conditions are common regardless of the reel holder type (standard feeder reel holder specification, or bucket
specification).
GCU is loaded on slot 14.
The slots that are used when loading W4P1 feeders at the end of a pallet are the same as for W8 feeders.
The following slot positions cannot be used with a G04 head.
M3II module: No.1, 20
M6II module: No.1, 45
M6IISP module: No.1, 43~44
