VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS

October 10, 2008

XPM2 / XPM3 Technical Reference Manual Conveyor Systems

COMPUTER CONTROLLED AUTO RAIL ADJUST

Auto Rail Adjust is:

! Standard, (installed on all ovens) ) An option, (NOT installed on all ovens)

DESCRIPTION

The Oven Control Program automatically adjusts the rail in/out to meet the board size entered in the PRODUCT

file in the Oven Control Program.

OPERATION

Run the Automatic rail adjust within the Oven Operation Program. NOTE: This operation may require a

password.

(The direction of travel of the rail and the speed of the width adjust may be selected by choices in the Oven

Operation Program.)

While conducting the following tests ensure that each rail moves to its minimum or maximum value and stop. The

rail adjust system is designed to stop at these positions.

1. Verify that the DC drive card is receiving 120 VAC power between terminals L1 and L2. If not, verify that K37

is energized.

2. Check that the I/O board relay A1-K22 is energized.

3. Measure and verify that the voltage at wire number V2+ at P45 pin 1 on the I/O board is +10 VDC.

4. If voltage is present, check the wiring at the signal input of the DC Drive.

5. If the preceding steps check out, measure the DC voltage output of the DC drive circuit board between

terminals A1 and A2. Voltage present should be 90-130 VDC. If there is no voltage present, the drive circuit

board is likely to be defective. Otherwise, adjust the SIGNAL ADJUST potentiometer on the DC drive board to

produce the 90-130 VDC.

If steps 1-5 have been performed and the rail motor still does not operate, refer to the Oven Schematics and

proceed with the following:

1. Verify the status of the rail limit switches by observing the status leds on the A40 board. These right angle

leds on the outer edge of the A40 board. A rail is not allowed to move if the corresponding limit switch led

on the A40 board is off in the desired direction to move. The A40 board will not energize relay A1-K22 if a

rail is not allowed to move due to a limit switch input not being present. This also applies for all of the

direction control relays A1-K23 through A1-K26.

2. Verify that the rail enable relay A1-K22 is energized.

3. Verify that the rail out relay A1-K23 or A1-K25 for the corresponding rail axis to move is energized.

4. If the correct relays are energized, check the associated wiring.

5. If the rail motor still does not turn, press an e-stop switch to disable 120 VAC control power.

6. Using an Ohm meter, verify that there is continuity through each rail limit switch.

(If either the switch is wired incorrectly or the rail is pressed up against the limit switch,

there should be no

continuity through the switch.)

7. Pull out the E-stop recently pressed and reset the E-Stop in the Oven Control Program.

VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS

October 10, 2008

XPM2 / XPM3 Technical Reference Manual Conveyor Systems

After the rail out function has been tested, the rail in function check out should be greatly reduced. Activate the

rail in function in the Oven Operation Program (this is assuming you have already logged into the software as

previously described). The part of the auto rail circuit which can be a problem is the rail in limit switch. The test

procedure for these components would be the same as described for the rail out circuit.

Rail Position Encoder

The final check out procedure is to verify that the rail position encoder feedback signal is being received and

processed by the computer.

A rotary quadrature encoder has a minimum of 2 sets of lines on a circular shaped disk instead of only one set on

a single ended encoder. One set of lines is 90 degrees out of phase with the other to allow the rotation direction of

a shaft to be determined. There is an optical decoder and output signal for each set of lines designated as output

channel A and output channel B. The rotation direction of a quadrature encoder is determined by monitoring which

output channel signal is ahead of or leading the other.

The rail width adjust on the XPM3 uses a 250 pulse per revolution quadrature encoder mounted on the end of a

lead screw. The lead screw is a ¾-10 acme screw, which translates to 10 turns to move a rail one-inch or 2.54 cm

of travel.

The two axis rail controller board 3152001 utilizes a quadrature counter for the auto rail option. On the 3152001

two axis controller a quadrature counter IC must be installed by inserting a HCTL-2016 device into a separate 16

pin DIP socket for each of the 2 possible auto rail axes to be controlled. U6 is the quadrature counter location for

the first axis and U7 is the quadrature counter location for the second axis. On the next generation 3152010 two

axis controller two quadrature counters are part of the base board through a single surface mount device. This was

due to the HCTL-2016 being obsoleted and discontinued by the manufacturer Agilent technologies.

3152001A Existing two axis rail control board.

U6 and U7 are only installed for auto rail options.

VITRONICS-SOLTEC REFLOW SOLDERING SYSTEMS

October 10, 2008

XPM2 / XPM3 Technical Reference Manual Conveyor Systems

3152010A future two axis controller board.

Each quadrature counter has a digital input filter that is synchronized with the 8 megahertz microcontroller clock on

the two axis rail controller board to filter out noise on the channel A and channel B inputs for each quadrature

encoder.

Each quadrature counter is set up to count on every state transition (count up and count down) from a quadrature

encoder. This is called 4X mode and results in the 250 pulse per revolution encoder used on the rail width adjust

producing an equivalent of 1000 counts per revolution instead of 250.

The quadrature counter used on the two axis rail controller is a 16 bit counter on the 3152001 board and a 24 bit

counter on the 3152010 board. Each quadrature counter counts independently of the microcontroller and does not

lose counts as long as power is not shut off to the oven.

Channel A leading channel B results in counting up. Channel B leading channel A results in counting down.
