How to Configure a Multi Line Job 4.1.1 Creating a New Multi Line Job Organizing a Multi Line Job SIPLACE SiCluster Multiline SIPLACE SiCluster Multiline 119 Closing multi line jobs ► Go to the SiCluster Multiline m enu …
How to Configure a Multi Line Job
Organizing a Multi Line Job
118 SIPLACE SiCluster Multiline SIPLACE SiCluster Multiline
4.1
4.1 Organizing a Multi Line Job
Organizing a Multi Line Job
Organizing a multi line job
1. Creates a multi line job
2. Saves a multi line job
3. Closes a multi line job
4. Opens multi line jobs which have already been opened
Selecting from all existing cluster jobs
► Go to the SiCluster Multiline menu and select the (1) icon.
⇨ The Organize Multi Line Jobs dialog box will open.
► Select a multi line job and open it with the Open Multi Line Job button or a doubleclick.
Selecting Open Multi Line Jobs
► Go to the SiCluster Multiline menu and select the (4) icon.
⇨ The list box shows the open multi line jobs.
► Select a multi line job from the list box.
Backup of multi line jobs
► Go to the SiCluster Multiline menu and select the (2) icon.
⇨ A backup will be created of the active multi line job.
How to Configure a Multi Line Job
4.1.1 Creating a New Multi Line Job Organizing a Multi Line Job
SIPLACE SiCluster Multiline SIPLACE SiCluster Multiline 119
Closing multi line jobs
► Go to the SiCluster Multiline menu and select the (3) icon.
⇨ This closes the active multi line job.
4.1.1
4.1.1 Creating a New Multi Line Job
Creating a New Multi Line Job
► Go to the Multi Line Recipes tab and select the
icon.
⇨ The Organize Multi Line Jobs dialog box will open.
► Right click with the mouse to open the context menu.
► Select a folder from the tree structure or create a new
folder with the New Folder function.
► Select the New Object function and enter the name of
the new multi line job.
► Open the multi line job with the Open Multi Line Job
button or a doubleclick.
How to Configure a Multi Line Job
Organizing a Multi Line Job 4.1.2 Opening an Existing Multi Line Job
120 SIPLACE SiCluster Multiline SIPLACE SiCluster Multiline
4.1.2
4.1.2 Opening an Existing Multi Line Job
Opening an Existing Multi Line Job
4.1.3
4.1.3 Copying/Renaming/Creating/Deleting a Multi Line Job
Copying/Renaming/Creating/Deleting a Multi Line Job
► Go to the Multi Line Recipes tab and select the
icon.
⇨ The Organize Multi Line Jobs dialog box will open.
► Open the multi line job with the Open Multi Line Job
button or a doubleclick.
► Go to the Multi Line Recipes tab and select the
icon.
⇨ The Organize Multi Line Jobs dialog box will open.
► Select the multi line job from the tree structure.
► Right click with the mouse to open the context menu.
► Select the relevant function from the context menu.
NOTICE!
When you use the "Copy to…" function, the existing opti-
mization results will not be copied. Only the ideal cycle
times will be copied.
