PRESTO Reference Manual USB In-System Programmer

100%1 / 101
PRESTO
Reference Manual
USB In-System Programmer
ASIX s.r.o.
Na Popelce 38/17
150 00 Prague
Czech Republic
www.asix.net
support@asix.net
sales@asix.net
ASIX s.r.o. reserves the right to make changes to this document, the
latest version of which can be found on the Internet.
ASIX s.r.o. renounces responsibility for any damage caused by the use
of ASIX s.r.o. products.
© Copyright by ASIX s.r.o.
Table of Contents
Introduction
10
1
PRESTO
11
2
11
2.1 Package Content
11
2.2 Features
11
2.3 Quick Start
11Windows2.3.1
12
2.4 Use
12Numerous Supported Devices2.4.1
12USB Connection2.4.2
12Programming of Placed Devices2.4.3
12Programming of Autonomous Devices2.4.4
13Programming Interface2.4.5
13Power Supply From Application2.4.6
13User Interface2.4.7
13Software2.4.8
13Debugging2.4.9
14
2.5 Controls and Connectors
14Programming Connector2.5.1
14GO Button2.5.2
15LED Indicators2.5.3
ON-LINE 15
ACTIVE 15
15USB Connector2.5.4
15
2.6 Connecting to Application
15Custom-made Connecting Cable2.6.1
16Programming in ZIF Socket2.6.2
16Connecting Procedure2.6.3
17Connection Examples2.6.4
PIC Microcontrollers 17
AVR Microcontrollers 18
AVR with TPI Interface (e.g. ATtiny10) 19
Atmel 8051 19
Cypress PSoC 20
MSP430 with TEST pin without SBW interface 20
MSP430 / CC430 with SBW interface 21
TI (Chipcon) CCxxxx 21
I2C Memory Chips 21
SPI Memory Chips 22
Microwire Memory Chips 22
JTAG Interface 22
23
2.7 Built-in Protection
24
2.8 Technical Specifications
24Limit Values2.8.1
24Operating Specifications2.8.2
25Declaration of Conformity and RoHS2.8.3
DRIVERS
26
3
26
3.1 Driver Installation
26Windows Operating Systems3.1.1
Windows 7 and later 26
Older supported Windows versions 26
27
3.2 Driver Updating
Usage under Linux
28
4
UP SOFTWARE
30
5
30
5.1 Abbreviations Used
