K87_FV_M-PL.pdf - 第91页
1 18 FV82D FV82D FV82D-0406 11 7 6 13 3 14 5 15 16 1 18 18 12 18 9 2 4 10 8 17 22 19 20 21 No. Part No. Part Name Q'ty Remarks Date Revised No. 1 K87-M1310-10X BODY ASSY 1 2 K87-M1 112-10X KNOCK PIN (FRONT) 1 3 K87-…
FV82C
FV82C
FV82C-0012
17
1
4
2
3
5
6
7
6
No. Part No. Part Name Q'ty Remarks Date Revised No.
1
K87-M12D0-00X
REEL HOLDER ASSY 1
2
K87-M12D1-00X
REEL PLATE ASSY 1
3
K87-M11D3-00X
TAPE SIZE STICKER 1
4
K87-M11D7-00X
CIRCLIP E 1
5
K87-M12D8-00X
REEL SIZE STICKER 1
6
K87-M12DA-00X
INDICATOR LEVER ASSY 1
7
K87-M111N-00X
SCREW,PAN HEAD + 2
1
18
FV82D
FV82D
FV82D-0406
11
7
6
13
3
14
5
15
16
1
18
18
12
18
9
2
4
10
8
17
22
19
20
21
No. Part No. Part Name Q'ty Remarks Date Revised No.
1
K87-M1310-10X BODY ASSY
1
2
K87-M1112-10X KNOCK PIN (FRONT)
1
3
K87-M1313-10X KNOCK PIN (REAR)
1
4
NEEDLE ROLLER
1
5
CIRCULAR RIVET
2
6
K87-M111A-10X SPRING
1
7
K87-M111B-00X BACK STOPPER AXIS
1
8
K87-M111C-00X PLANE WASHER
1
9
K87-M111D-00X PUSH PIN
1
10
K87-M111E-10X SPRING
1
11
K87-M111F-10X STOPPER PIN
1
12
K87-M111G-10X PUSH PIN
1
13
K87-M131H-10X BACK STOPPER
1
14
K87-M111L-00X BARB CONNECTOR STRAIGHT
1
15
K87-M111M-00X GASKET
1
16
K87-M111N-00X SCREW,PAN HEAD +
1
17
K87-M111P-00X SCREW,FLAT HEAD +
1
18
K87-M111R-00X SCREW,SET
4
19
K87-M1320-00X SPROCKET
1
20
K87-M132A-10X RACKING LEVER ASSY
1
21
K87-M112D-00X COIL SPRING
1
22
K87-M112L-10X SPROCKET AXIS ASSY
1
FV82D
FV82D
FV82D-0012
18
2
18
15
16
4
14
18
2
17
1
1
13
3
4
12
6
11
7
8
9
10
8
5
No. Part No. Part Name Q'ty Remarks Date Revised No.
1
K87-M111S-00X
SCREW,FLAT HEAD + 6
2
K87-M111U-00X
SCREW FLANGE NUT 2
3
K87-M111V-00X
SCREW,SET 1
4
K87-M111X-00X
SCREW,SET 2
5
K87-M1131-00X
CLAMP LEVER UNIT 1
6
K87-M1132-10X
CLAMP LEVER ASSY 1
7
K87-M113A-00X
CLANK ARM ASSY 1
8
K87-M113D-00X
ARM 2
9
K87-M113E-00X
HINGE PIN 2 1
10
K87-M11D7-00X
CIRCLIP E 2
11
K87-M113L-10X
CLAMP LEVER AXIS 1
12
K87-M113M-00X
AXIS PIN 1
13
K87-M113H-00X
PUSH PIN 1
14
K87-M1340-10X
TAPE GUIDE ASSY 1
15
K87-M114A-10X
LOCK LEVER ASSY 1
16
K87-M114L-10X
SUPPORT PLATE 1
17
K87-M114M-10X
SUPPORT PLATE 1
18
K87-M114N-00X
GUIDE AXIS 2
