16 Single lane and dual lane conveyor Placement modes Synchronous mode In synchronous mode, two boards of the same size are transported into the pla ce- ment position at the same time. They are processed as a common pane…
15
Single lane and dual lane conveyor
Technical data
Single lane conveyor Dual lane conveyor Dual lane conveyor in
"single lane con-
veyor" mode
Board dimensions
(length x width)
Standard 50 mm x 50 mm to
450 mm x 685 mm
a
a) Board width up to 560 mm as standard. Board widths up to 685 mm available on request.
50 mm x 50 mm to
450 mm x 320 mm
50 mm x 50 mm to
450mm x 600mm
b
Long board
b
b) With input and output conveyor extension only.
50 mm x 50 mm to
850 mm x 685 mm
b
50 mm x 50 mm to
850 mm x 320 mm
50 mm x 50 mm to
850mm x 600mm
b
Stationary conveyor side Right or left Right, left or outer
Automatic electrical width adjustment? Standard
PCB thickness
Standard 0.3
c
mm to 4.5 mm
c) Thinner than 0.3 mm on request
PCB warpage See page 18
PCB weight
d
d) The board weight value refers to the weight of the board plus the weight of the components.
Max. 3.0 kg
e
e) Standard 3.0 kg. Board weight up to 8.0 kg on request
Max. 2.0 kg
f
f) Standard 2.0 kg. Board weight up to 5.0 kg on request.
Max. 2.0 kg
f
Clearance on PCB underside 25 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface SMEMA or IPC-HERMES-9852
Component-free PCB handling edge 3 mm
PCB changeover time
Single lane conveyor
Dual lane conveyor
g
g) 0 seconds in asynchronous mode, otherwise 1.5 seconds.
< 1.5 seconds
0 seconds
Important notes
When setting up a placement machine (TX, SX, or X-Series S) next to a SIPLACE CA4 V2, please be aware of the limited room
between the two placement machines. In these cases, use suitable conveyor extensions to create room of 0.5m for the operator
between the two machines.
To achieve top placement performance, fit the first machine in a SIPLACE CA4 V2 line with an input conveyor extension and the
last machine in the line with an output conveyor extension.
16
Single lane and dual lane conveyor
Placement modes
Synchronous mode
In synchronous mode, two
boards of the same size are
transported into the place-
ment position at the same
time. They are processed as
a common panel. When
using products with greatly
differing placement content,
common optimization
increases the performance of
the whole content on both
boards.
Asynchronous mode
In asynchronous mode, only
one board on a conveyor
lane is processed. At the
same time, another board on
the second conveyor lane is
moved into the placement
position. This saves the full
conveying time of one board,
thus considerably increasing
performance, particularly for
boards with a short cycle
time.
I-Placement
The SIPLACE line achieves
top placement performance
with the use of I-Placement.
In this mode, the two heads
work simultaneously and
populate the PCB on the cor-
responding conveyor side,
totally independently of one
another. Short distances fur-
ther increase the output.
Borrow Performance
By facilitating simultaneous
production of two boards with
different contents in one line,
Borrow Performance is the
ideal addition to I-Placement.
In placement machines with
Borrow Performance, both
heads place the same board
in alternation The board in
the other conveyor lane is
simply transported through
the system. This makes it
possible to achieve the same
cycle time for both boards,
despite the different place-
ment contents.
Convoy Mode
When processing boards
with lengths shorter than 175
mm, Convey Mode moves
more boards into the place-
ment area and input con-
veyor section. While one
board is being processed,
the second one waits directly
behind it. The transportation
time is therefore reduced sig-
nificantly, especially in I-
Placement mode.
17
Single lane and dual lane conveyor
I-Placement
Alternating placement mode
Alternating placement or
I-Placement mode
Distance of outer conveyor
edges: 680 mm, 2 lanes, outer
conveyor edges fixed
Alternating placement mode
Distance of outer conveyor
edges: 601 mm, dual conveyor
in single conveyor mode, right
conveyor edge fixed
a
max. 320
Movable conveyor side
Stationary conveyor side
a) The diagram only shows settings with a fixed righthand conveyor edge. A setting with the stationary conveyor
edge on the left is also possible. All dimensions in millimeters.
max. 320
344
680 (27“)
Min. 35
-344
+258
max. 601
Adjustable conveyor side position and max. PCB width
Conveyor side position Max. PCB width Distance of fixed sides to one another, for various fixed side
position settings
Outside Right or left
234.2 mm 216 mm 468.4 mm 251.7 mm
254 mm 236 mm 508 mm 272 mm
259.7 mm 242 mm 519.4 mm 277.2 mm
268 mm 250 mm 536 mm 286 mm
268 mm SMEMA 250 mm 536 mm 285.5 mm
281 mm 260 mm 562 mm 299 mm
281 mm SMEMA 260 mm 562 mm 298.5 mm
320 mm 300 mm 640 mm 337.5 mm
344 mm 320 mm 688 mm 362 mm
Customized Max. 320 mm Max. 688 mm Max. 362 mm
