54 List of options Placement machine A vailable options CA4 V2 Notes Adapter X X Roadrunne r , S linear vib ratory feeder and label prese nter can be config ured on a component trolley X with this adapter . Linear Dip Mo…
53
List of options
Placement machine
Available options CA4 V2 Notes
Vacuum tooling L330 x 315 X
Vacuum tooling L625 x W615 X
Vacuum tooling DM 300 ST 0.5 X Temperature-controlled vacuum tool-
ing
Vacuum tooling DM 300 ST 1.2 X Temperature-controlled vacuum tool-
ing
Thick board X
Hand guard for conveyor X
Dummy feeder module X
Barcode-controlled production including WDTL X
WDTL inkspots X
Station-wise download X
Borrow Performance X
Nozzle changer X Depends on placement head.
Nozzle changer "row 2" X Depends on placement head.
Component trolley X X
SmartFeeder X, 8 mm to 104 mm X
SIPLACE SmartFeeder Xi, 4 mm, 8 mm and 2x8 mm X
Splice point recognition for X feeder modules X
Mount of additional tape reel X
SIPLACE MeasuringFeeder X X
SIPLACE LDU 2 X X
SIPLACE Glue Feeder X
SIPLACE PowerConnector X X
Input conveyor extension X
Output conveyor extension X
110/208 V conversion kit X
2D board barcode readers X
PCB barcode reading with PCB camera X
External pre-setup area X
Interior lighting X
Virtual inkspot handler X Electronic substrate mapping
54
List of options
Placement machine
Available options CA4 V2 Notes
Adapter X X Roadrunner, S linear vibratory feeder
and label presenter can be configured
on a component trolley X with this
adapter.
Linear Dip Module LDU 2 X With pickup area restrictions. Not on
SWS.
SIPLACE JTF-M -- Only in conjunction with the fixed
component table and the SIPLACE
MultiStar in high installation position
(CPP_H)
Component table, fixed installation -- For SIPLACE JTF-M and LDU-X
Tape reels, level 2 X
Earthquake anchor brace X
OSC package X
OnBoard PCB inspection X
15" monitor with keyboard X
55
Configuration overview
Head configurations
Placement head
types
SIPLACE SpeedStar (C&P20 M2)
SIPLACE MultiStar (CPP M)
Placement area 1 Placement area 2
C&P20 M2 C&P20 M2 C&P20 M2 C&P20 M2
C&P20 M2 C&P20 M2 CPP M CPP M
CPP M CPP M CPP M CPP M
Configurations/options C&P20 M2 CPP M
SWS Flip-Chip X X
a
a) Collect&Place mode only
SWS Die Attach X X
b
LDU X on X table X X
LDU 2X on X table X X
LDU X on SWS X X
Nozzle changer X
b
b) 6 magazines with 72 nozzle garages
X
Nozzle changer, "row 2" X X
JTF-M X X
Component camera, type 45 -- X
Component camera, type 48 X --
Component camera, type 49 X --
Component camera, type 34 X X
Single lane conveyor, fixed side right X X
Single lane conveyor, fixed side left X X
Dual lane conveyor X X
Panel lane conveyor X X
Wafer lane conveyor X X
