User manual E by SIPLACE 3 Technical data and assemblies
From software version SC 712.1 Edition 05/2019 3.1 Overview of technical data
103
3.1.5 PCB conveyor - data
3
3
Single conveyor
Standard dimensions (length x width)
With buffering
Without buffering
*a
*)a On request
50 mm x 50 mm to 460 mm x 460 mm
50 mm x 50 mm to 490 mm x 460 mm
With “Long Board”option 1030 (length x width)
Single step mode
Two step mode
a
50 mm x 50 mm to 610 mm x 460 mm
50 mm x 50 mm to 1030 mm x 460 mm
With “Long Board”option 1200 (length x width) 70 mm x 50 mm to 1200 mm x 460 mm
Stationary conveyor side Right, Left
Automatic electrical width adjustment Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page
140
PCB weight
*b
Standard
*)b The board weight value refers to the weight of the board plus the weight of the components.
max. 2.0 kg
Clearance on PCB underside
*c
*)c The free positioning of support pins is limited by the stop bar.
25 mm
PCB conveyor height
Standard
Option
900 mm to 930 mm
950 mm
Type of interface:
Standard: SMEMA
Component-free PCB handling edge 3.0 mm
PCB changeover time
Single conveyor < 1.5 seconds
Important notes
When setting up a machine (S; F-, HS-, HF-, X- or D-Series) next to a E by SIPLACE, be aware that there is limited room between the two
machines. In these cases, use suitable conveyor extensions to create room of 0.5m for the operator between the two machines.
3 Technical data and assemblies User manual E by SIPLACE
3.2 Ambient conditions and connection values From software version SC 712.1 Edition 05/2019
104
3.2 Ambient conditions and connection values
3.2.1 Ambient conditions for packaging, transportation and storage
3
3.2.2 Ambient conditions for machine operation
3
3.2.3 Electrical ratings
3
3
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75 % (no higher than 45% on average to prevent any
possibility of condensation on the machine)
Ambient pressure > 890 mbar (corresponds to 1000 m above mean sea level)
PLEASE NOTE
Use of a residual current protection device
The low ground leakage current of the system makes it possible to use an upstream
residual current protection device at the customer end. This must be all-current sen-
sitive (RCD type B).
Electrical ratings
Supply voltage Fuse
Main power supply 3 x 200 V~ up to 3 x 230 V~; ± 10 %; 50/60 Hz)
*a
3 x 380 V~ up to 3 x 415 V~; ± 10 %; 50/60 Hz
3 x 16 A characteristic C
*b
3 x 16 A characteristic C
*b
Mains power connection Cable 4 x 4 mm² with CEKON connector
Energy consumption
Energy consumption
with
vacuum pump
Nominal active power
1.8 kW
Nominal apparent power
2.3 kVA
*)a With adapter kit (US option)
*)b Usage worldwide (except North America): e.g. Siemens circuit breaker 5SY8 316-7
or
EATON Industries circuit breaker (miniature circuit breaker) FAZ-C16/3 16 A 3p
For North America: e.g. Siemens circuit breakers in accordance with IEC and UL 489 (order no.: 5SJ4 316-7HG42)
or
EATON Industries circuit breaker FAZ-C16/3-NA 16A 3p (UL 489, CSA C22.2 no. 5, IEC 60947-2)
User manual E by SIPLACE 3 Technical data and assemblies
From software version SC 712.1 Edition 05/2019 3.2 Ambient conditions and connection values
105
3.2.4 Compressed air supply and compressed air specification
3
Compressed air supply
Compressed air pressure values
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air connection R 3/4" inner thread (pipe thread) with 1/2" hose connection
Compressed air consumption
*a
Placement head configura-
tion
Compressed air
consumption
*b
with
vacuum pump
*c
E by SIPLACE CP14
CP12
CP12 / PP
CP6 / PP
TH
90 Nl/min
90 Nl/min
140 Nl/min
140 Nl/min
185 Nl/min
Compressed air specification according to DIN ISO 8573-1:2010
Particle size (ISO class 1) 0.1 µm
Particle density (ISO class 1) 0.1 mg/m³
Maximum oil content (ISO class 1) 0.01 mg/m³
Pressure dewpoint (ISO class 4) + 3°
*)a Average consumption values
*)b Under normal atmospheric conditions at 20°C and 1013 hPa.
*)c Vacuum pump for SIPLACE CP14/CP12/CP6 head only.
