6 Station extensions User manual E by SIPLACE 6.3 SIPLACE JTF-MW From software version SC 712.1 Edition 05/201 9 294 6.3.5.5 Warning labels on the SIPLACE JTF-MW 6 Fig. 6.3 - 4 Warning labels on SIPLACE JTF-MW – W204, it…
User manual E by SIPLACE 6 Station extensions
From software version SC 712.1 Edition 05/2019 6.3 SIPLACE JTF-MW
293
6.3.5.3 Danger of Crushing at SIPLACE JTF-MW
Areas of the SIPLACE JTF-MW at which there is a danger of crushing 6
– Magazine and pusher assembly
– Tray clamp
– Cylinder for tray clamp
– Feeder base - movable tray stack
– Recess for separation rods
– Feeder base - movable tray stack
– Tray return assy
– Feeder base - drive belt
6.3.5.4 Safety Instructions for Transporting the Module
6
DANGER
Danger of crushing
There is a risk of injuries by pinch points or a risk of crushing by reaching into the feeder or from
loose clothing which could get into the feeder during operation.
Observe correct handling and the safety instructions.
Do not reach into the feeder while it is running.
Maintain an adequate safety distance.
CAUTION
High weight
The heavy weight of the module could cause injuries if the module is not handled correctly.
Do not lift or carry the module alone.
During removal, remember that the SIPLACE JTF-MW (~ 60 kg) is heavy. You might need
to enlist the help of a second person.
6 Station extensions User manual E by SIPLACE
6.3 SIPLACE JTF-MW From software version SC 712.1 Edition 05/2019
294
6.3.5.5 Warning labels on the SIPLACE JTF-MW
6
Fig. 6.3 - 4 Warning labels on SIPLACE JTF-MW
– W204, item no. 03009343-01
Warning label W204
6
Quantity per SIPLACE JTF-MW: 2
W 204
W 204
Heavy weight
6
6
6
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the SIPLACE JTF-MW while it is running
User manual E by SIPLACE 6 Station extensions
From software version SC 712.1 Edition 05/2019 6.3 SIPLACE JTF-MW
295
Warning label heavy weight
Quantity per SIPLACE JTF-MW: 1
6
6
6
Heavy weight!
The heavy weight of the SIPLACE JTF-MW (
~ 60 Kg) could cause
injuries if the module is not handled correctly.
Do not lift or carry the module alone.
Use lifting aids and proper lifting techniques when removing
or replacing.
You might need to enlist the help of a second person.
