User manual SIPLACE SX1/SX2 6 Station extensions From software version SC 706.1 SP1 Versi on 10/2014 6.2 Waffle pack changer (WPC5/WPC6) 315 6.2.3 Overview WPC6 Item no. 001 19828-xx WPC6 on SIPLACE SX1/SX2 6 Fig. 6.2 - …
6 Station extensions User manual SIPLACE SX1/SX2
6.2 Waffle pack changer (WPC5/WPC6) From software version SC 706.1 SP1 Version 10/2014
314
6.2.2 Overview WPC5
Item no. 00119827-xx WPC5
6
Fig. 6.2 - 1 WPC5 on the SIPLACE SX1/SX2
(1) WPC5
(2) Component trolley with 30 tracks
(1)
(2)
User manual SIPLACE SX1/SX2 6 Station extensions
From software version SC 706.1 SP1 Version 10/2014 6.2 Waffle pack changer (WPC5/WPC6)
315
6.2.3 Overview WPC6
Item no. 00119828-xx WPC6 on SIPLACE SX1/SX2
6
Fig. 6.2 - 2 WPC6 on the SIPLACE SX1/SX2
(1) WPC6
(2) Non-stop module
(3) Component trolley with 30 tracks
(1)
(3)
(2)
6 Station extensions User manual SIPLACE SX1/SX2
6.2 Waffle pack changer (WPC5/WPC6) From software version SC 706.1 SP1 Version 10/2014
316
6.2.4 Safety instructions
6
6
6
6.2.5 Notes on operation
6
6.2.5.1 Operation, maintenance, service
For detailed documentation of the operation, maintenance and servicing of the waffle pack
changer, refer to the manuals supplied with your waffle pack changer.
WARNING
Risk of injuries!
Risk of injuries at the waffle pack changer when the machine is running.
Do not reach into the gaps between the waffle pack changer and the machine base
while the machine is running.
WARNING
Requirement for operation: Docking the waffle pack changer onto the machine!
The waffle pack changer may NOT be operated unless it is docked into the machine.
Only connect/disconnect the control cable for the waffle pack changer to/from the
connection socket when the waffle pack changer is docked onto the machine.
Only connect/disconnect the power supply cable to/from the external power supply if
the waffle pack changer is docked onto the machine.
PLEASE NOTE
Observe the order of switching on
If there are two waffle pack changers installed in one machine, observe the order of
switching on. If this is not observed, errors could occur (e.g. CAN switch error).
Always switch the waffle pack changer on before the SIPLACE machine.
In the event of an error, switch the waffle pack changer and the SIPLACE machine
off and then switch them back on again in the right order. Observe the required wait-
ing periods.
