User manual SIPLACE SX1/SX2 2 Operational safety From software version SC 706.1 SP1 Version 10/2014 2.2 Warning labels 47 2.2.5 W arning labels on the power supply unit an d transformer 2 W206 in fig. 2.2 - 6 , page 47 i…
2 Operational safety User manual SIPLACE SX1/SX2
2.2 Warning labels From software version SC 706.1 SP1 Version 10/2014
46
2
2.2.4.1 Warning label W205 on the used tape chute
2
Fig. 2.2 - 5 Warning label W205 on the used tape chute
W205, item no. 03009344-01
WARNING
Risk of cuts!
Risk of cutting when working on the cutter!
Disconnect the machine from the power and compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Wear robust protective gloves when working on the tape cutter.
W205
User manual SIPLACE SX1/SX2 2 Operational safety
From software version SC 706.1 SP1 Version 10/2014 2.2 Warning labels
47
2.2.5 Warning labels on the power supply unit and transformer
2
W206 in fig. 2.2 - 6, page 47 item no. 03009345-01 (quantity per machine: 2).
W206 in fig. 2.2 - 8
, page 49 item no. 03009345-01 (quantity per machine: 2).
Fig. 2.2 - 6 Warning label W206, cover of transformer and power supply unit
W206, in front of the transformer unit cover
W206, on the side cover to the power supply unit
DANGEROUS VOLTAGES!
The labeled parts are still live when the main power switch is off.
Disconnect the machine from the mains before servicing it.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
W206
2 Operational safety User manual SIPLACE SX1/SX2
2.2 Warning labels From software version SC 706.1 SP1 Version 10/2014
48
2.2.5.1 Warning labels W206, W250, W251 on the inside of the sector doors
2
Fig. 2.2 - 7 Warning labels on the inside of the sector doors
W251, on the inside of the sector doors, item no. 03079298-xx
W250, on the inside of the sector doors, item no. 03079262-xx
W206, on the inside of the sector doors, item no. 03009345-xx
W206, on the inside of the power supply unit (see also fig. 2.2 - 8
, page 49 )
The machine may only be started when the stopper is fitted and
the door is closed.
(W250)
(W206)
(W251)
W206
W250, W251, W206
on the inside of the door
W250, W251, W206
on the inside of the door
(W250)
(W206)
(W251)
