Introduction Abbreviations SIPLACE on the World Wide Web (WWW) 42 Long Board Option
Introduction
Release History Abbreviations
Long Board Option 41
1.3.4 Release History
1.3.5 SIPLACE on the World Wide Web (WWW)
Log into our SIPLACE® homepage at http://www.siplace.com.
► You can choose between the German and English versions.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can access the
SIPLACE User Group
. Here you can call up special
information about our placement systems e.g.
▪ Technical documentation,
▪ Technical information,
▪ Spare parts lists etc.
Registration for the user group is very simple:
► Click on the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.4 Abbreviations
Release Changes
12/2011 First edition
Abbreviations Description
LBO Long Board Option
PCB Board
Introduction
Abbreviations SIPLACE on the World Wide Web (WWW)
42 Long Board Option
Brief Description
"Long board for single conveyor SX1/SX2" option [00120625-xx] Parts, Equipment and Tools
Long Board Option 43
2 Brief Description
The "Long Board Options" facilitates placement of boards which exceed the specified board length, up
to a maximum length of 610 mm.
2.1 Parts, Equipment and Tools
▪ Standard tool
▪ Cable ties
▪ Allen wrench, size 2.5 (with shorter elbow piece if possible)
▪ "Long board for single conveyor SX1/SX2" option [00120625-xx] (see below) or
"Long board for dual conveyor SX1/SX2" option [00120626-xx] (see below)
▪ Depth measuring gauge (200 mm) [03079617-xx], if required
2.2 Scope of Delivery
2.2.1 "Long board for single conveyor SX1/SX2" option [00120625-xx]
This package contains the Assembly Instructions "Long Board Option SX1/SX2 from 09/2011 (FS02)"
[00197187-xx], a licence for the clearing of the option and the following parts:
Quantity Designation Item No.
1 x Guidance rail right B 03088180-xx
1 x Guidance rail left B 03088179-xx
1 x Stop guide rail right 599 complete 03088196-xx
1 x Stop guide rail left 599 complete 03088191-xx
1 x Support socket 03085311-xx
1 x Stopper 25 SX pneumatic complete 03084034-xx
1 x Sheet 03084255-xx
1 x Valve unit stopper complete 03084466-xx
0.5 M Compressed-air hose PUN-3x0.5-BL 03053429-xx
8 x Spring-mounted PCB support 94 mm 03082256-xx
1 x Lifting table plate LBO B2 SC 03070780-xx
1 x Cover 2 right stopper rail LBO SX12 03091990-xx
1 x Spacer LBO 03091992-xx
2 x Distance washer M3 / H=2 mm 03092259-xx
2 x DIN 125-A 3.2-140HV-A2 00316904-xx
1 x ISO 4762 - M 3 x 35-A2-70 03043114-xx
1 x DIN-EN-ISO7380-M3x25-A2-70 03045198-xx
2 x Groove ball bearing 3*10*4 623-2Z 00305841-xx
2 x DIN7-3h8x14-A2 03057879-xx
2 x ISO 4762 - M 3 x 8-A2-70 03042542-xx
