Brief Description

"Long board for single conveyor SX1/SX2" option [00120625-xx] Parts, Equipment and Tools

Long Board Option 43

2 Brief Description

The "Long Board Options" facilitates placement of boards which exceed the specified board length, up

to a maximum length of 610 mm.

2.1 Parts, Equipment and Tools

▪ Standard tool

▪ Cable ties

▪ Allen wrench, size 2.5 (with shorter elbow piece if possible)

▪ "Long board for single conveyor SX1/SX2" option [00120625-xx] (see below) or

"Long board for dual conveyor SX1/SX2" option [00120626-xx] (see below)

▪ Depth measuring gauge (200 mm) [03079617-xx], if required

2.2 Scope of Delivery

2.2.1 "Long board for single conveyor SX1/SX2" option [00120625-xx]

This package contains the Assembly Instructions "Long Board Option SX1/SX2 from 09/2011 (FS02)"

[00197187-xx], a licence for the clearing of the option and the following parts:

Quantity Designation Item No.

1 x Guidance rail right B 03088180-xx

1 x Guidance rail left B 03088179-xx

1 x Stop guide rail right 599 complete 03088196-xx

1 x Stop guide rail left 599 complete 03088191-xx

1 x Support socket 03085311-xx

1 x Stopper 25 SX pneumatic complete 03084034-xx

1 x Sheet 03084255-xx

1 x Valve unit stopper complete 03084466-xx

0.5 M Compressed-air hose PUN-3x0.5-BL 03053429-xx

8 x Spring-mounted PCB support 94 mm 03082256-xx

1 x Lifting table plate LBO B2 SC 03070780-xx

1 x Cover 2 right stopper rail LBO SX12 03091990-xx

1 x Spacer LBO 03091992-xx

2 x Distance washer M3 / H=2 mm 03092259-xx

2 x DIN 125-A 3.2-140HV-A2 00316904-xx

1 x ISO 4762 - M 3 x 35-A2-70 03043114-xx

1 x DIN-EN-ISO7380-M3x25-A2-70 03045198-xx

2 x Groove ball bearing 3*10*4 623-2Z 00305841-xx

2 x DIN7-3h8x14-A2 03057879-xx

2 x ISO 4762 - M 3 x 8-A2-70 03042542-xx

Brief Description

Scope of Delivery "Long board for dual conveyor SX1/SX2" option [00120626-xx]

44 Long Board Option

2.2.2 "Long board for dual conveyor SX1/SX2" option [00120626-xx]

Quantity Designation Item No.

2 x Support socket 03085311-xx

2 x Stopper 25 SX pneumatic complete 03084034-xx

2 x Sheet 03084255-xx

2 x Valve unit stopper complete 03084466-xx

2 x Stop guide rail right 599 complete 03088196-xx

2 x Stop guide rail left 599 complete 03088191-xx

2 x Guidance rail right B 03088180-xx

2 x Guidance rail left B 03088179-xx

1.0 M Compressed-air hose PUN-3x0.5-BL 03053429-xx

12 x Spring-mounted PCB support 94 mm 03082256-xx

1 x Cover 2 left stopper rail LBO SX12 03091991-xx

2 x Lifting table plate LBO B2 DC 03070791-xx

2 x Spacer LBO 03091992-xx

1 x Cover 2 right stopper rail LBO SX12 03091990-xx

4 x Distance washer M3 / H=2 mm 03092259-xx

4 x DIN 125-A 3.2-140HV-A2 00316904-xx

2 x ISO 4762 - M 3 x 35-A2-70 03043114-xx

2 x DIN-EN-ISO7380-M3x25-A2-70 03045198-xx

4 x ISO 4762 - M 3 x 8-A2-70 03042542-xx

4 x Groove ball bearing 3*10*4 623-2Z 00305841-xx

4 x DIN7-3h8x14-A2 03057879-xx
