Annex
Conveyor Control TSP 400 TSP400 Jumper
64 Long Board Option
4.4.6 TSP400 Jumper
4.4.7 TSP400 LEDs
JP1 2-3 Terminating resistor for CAN bus of machine: Off
JP2 1-2 Terminating resistor for CAN bus of conveyor lane 1 or 2: on
JP3 1-2 Trigger signal stopper: Internal
H1 Error
H2 Mode
H3 CAN bus activity of machine
H4 CAN bus activity of conveyor lane 1 or 2
H5 40V voltage supply is present
H6 24V voltage supply is present
H7 24V switched through (supply to brake is present)
