Annex Conveyor Control TS P 400 TSP400 Jumper 64 Long Board Option 4.4.6 TSP400 Jumper 4.4.7 TSP400 LEDs JP1 2-3 Terminating resistor for CAN bus of machine: Off JP2 1-2 Terminating resistor for C AN bus of c onveyo r la…
Annex
TSP400 Connector Conveyor Control TSP 400
Long Board Option 63
4.4.2 TSP400 Connector
4.4.3 TSP400 Fuses
4.4.4 TSP400 Potentiometer
4.4.5 TSP400 Switches and Buttons
X1 Siemens interface, predecessor station X21 Board sensor placement area
X2 Siemens interface, successor station X22 Spare
X3 SMEMA interface, predecessor station X23 Board sensor output area
X4 SMEMA interface, successor station X24 Sensor conveyor side width adjustment
unit 1
X5 Power supply X25 Sensor conveyor side width adjustment
unit 2
X26 Sensor cylinder width adjustment unit 1
X7 CAN bus to machine controller X27 Sensor cylinder width adjustment unit 2
X8 V24 interface for troubleshooting (debug) X28 Spare
X9 Interface to board TSP400E (optional) X29 Stopper Long Board Option coding (togeth-
er with X37)
X10 Motor for conveyor X30 Spare
X11 Width adjustment motor X31 Spare
X12 Motor for lifting table X32 Pneumatic valve width adjustment unit 1
X33 Pneumatic valve width adjustment unit 2
X14 CAN bus to conveyor lane X34 Spare
X15 Track signals for conveyor motor X35 Stopper for input area
X16 Track signals for width adjustment motor X36 Stopper for placement area
X17 Track signals for lifting table motor X37 Stopper Long Board Option (together with
X29)
X18 Brake for lifting table X38 Stopper for output area
X19 Programming interface for development X39 Spare
X20 Board sensor input area X40 Programming interface for development
F1 [03079942-xx] Microfuse 5x20 /
T 2A / ceramic
T2A Fuse protection
24V
(sensors, control system supply)
F2 [03078843-xx] Microfuse 5x20 /
T 6.3A / ceramic
T6.3A Fuse protection
40V
(supply to drives)
F3 Self-restoring SMD fuse Polyswitch set for 24 V (supply to lifting table brake), not
replaceable
G1 Setting the zero point of the control loop for the lifting table/conveyor belt/width adjustment motor
(needs to be performed only once
G2 by the manufacturer and is then sealed with locking varnish). The potentiometer will be dis-
pensed with in future
G3 and replaced with an eSW teach function.
S1 Reset XC167 (used for eSW development only)
S2 Reset XC167 (used for eSW development only)
S3 Configuration for single and dual conveyor
Annex
Conveyor Control TSP 400 TSP400 Jumper
64 Long Board Option
4.4.6 TSP400 Jumper
4.4.7 TSP400 LEDs
JP1 2-3 Terminating resistor for CAN bus of machine: Off
JP2 1-2 Terminating resistor for CAN bus of conveyor lane 1 or 2: on
JP3 1-2 Trigger signal stopper: Internal
H1 Error
H2 Mode
H3 CAN bus activity of machine
H4 CAN bus activity of conveyor lane 1 or 2
H5 40V voltage supply is present
H6 24V voltage supply is present
H7 24V switched through (supply to brake is present)
