1. The conten ts inclu de all features of NeoDen4, so me o f which m ay n ot be e quipped on your machine . 2. Basic training a nd b asic SMT knowledge are req uired for an ope rator. 3. For routine insp ection and repai…
5.3
Nozzle 42
5.4
Maintenance...........................................................................................................................43
5.4.1 Take effective measures to reduce/ avoid malfunction..............................................43
5.4.2 Maintenance of device................................................................................................44
5.5
Placement failure analysis and troubleshooting....................................................................45
5.6
Related issues during solder paste printing process............................................................. 46
EC Declaration of Conformity............................................................................................................ 48
1.The contents include all features of NeoDen4, some of which may not be equipped on your
machine.
2.Basic training and basic SMT knowledge are required for an operator.
3.For routine inspection and repair, please contact sales for operating instruction.
Safety Device, Warning Label
1.Before operation, please ensure the presence of adequate guarding and safety devices to avoid
accident.
2.When tear down the safety device, please keep it in the original position, and make sure it works
in good condition
3.When failures happen on safety device, cannot run the machine after remove safety device. In
case any injuries or casualty accident.
Usage
1.You agree that you will solely be responsible for your use of any products and services provided
to you and that you will use our products and services legally and only for the purposes that they
are intended to be used for.
2.You agree that you will not misuse the products and/or services supplied and that you will abide
by any laws applicable to this agreement or the operation of it.
IMPO AN
P AS AD HIS US MANUA
OMP Y FO OP A ING
HIS UNI AND AIN HIS OOK
FO FU U F N
CAUTION
Power off: After cut off main power supply, pull the plug or disconnect the power cable from the
power supply.
1.When an exception or failure happens, or power failure, please terminate the operation of
Windows, and power it off.
2.Power off prior to cleaning and repairing in case of any accidents.
3.When pull the plug, please hold the head instead of wire.
Transport
1.Take necessary security measures, to prevent upside down or fall when lifting or moving.
Open
1.
Please read all instruction in the wooden box
2.
Do not cut the packing tape by knife, to avoid scratch the machine
3.Keep all packing material.
Installation
1.
Please put the machine in a horizontal place.
2.
Please keep the floor clean and dry, and the machine should be grounded, to prevent
electric shock or leakage.
Prepare work
1.
Make sure the power cable no damage, no shedding and no loose.
2.
Do not put hand in the working area.
Maintenance
1.
Repair and calibration should be operated by skilled mechanical technician. When
replacing parts, please use the part which are supplied by NeoDen. We are not responsible for
any accident result from using nonstandard part.
2.
In order to prevent electric shock caused by unskilled operation, the electrical repairs,
maintenance (including wiring), should be operated by professional electrician or the technical
staff from NeoDen or our distributors.
3.
Make sure Bolts - Nuts are tighten after repair, calibration or replacing any part.
Working Environment
1.Do not use machine in a noisy environment, such as high frequency welding machine.
2.Do not use machine if the power supply voltage exceeds the rated voltage
±
10%.
3.Do not use machine and pull the plug when thunder to avoid any accident caused by damaged
electrical component.
