CAUTION
Power off: After cut off main power supply, pull the plug or disconnect the power cable from the
power supply.
1.When an exception or failure happens, or power failure, please terminate the operation of
Windows, and power it off.
2.Power off prior to cleaning and repairing in case of any accidents.
3.When pull the plug, please hold the head instead of wire.
Transport
1.Take necessary security measures, to prevent upside down or fall when lifting or moving.
Open
1.
Please read all instruction in the wooden box
2.
Do not cut the packing tape by knife, to avoid scratch the machine
3.Keep all packing material.
Installation
1.
Please put the machine in a horizontal place.
2.
Please keep the floor clean and dry, and the machine should be grounded, to prevent
electric shock or leakage.
Prepare work
1.
Make sure the power cable no damage, no shedding and no loose.
2.
Do not put hand in the working area.
Maintenance
1.
Repair and calibration should be operated by skilled mechanical technician. When
replacing parts, please use the part which are supplied by NeoDen. We are not responsible for
any accident result from using nonstandard part.
2.
In order to prevent electric shock caused by unskilled operation, the electrical repairs,
maintenance (including wiring), should be operated by professional electrician or the technical
staff from NeoDen or our distributors.
3.
Make sure Bolts - Nuts are tighten after repair, calibration or replacing any part.
Working Environment
1.Do not use machine in a noisy environment, such as high frequency welding machine.
2.Do not use machine if the power supply voltage exceeds the rated voltage
±
10%.
3.Do not use machine and pull the plug when thunder to avoid any accident caused by damaged
electrical component.
1
1.
Brief Introduction
1.1
Product Introduction
The fourth-generation model NeoDen4 is NeoDen Tech’s independent product, with completely independent
intellectual property. Its high precision vision system made it stand out in desktop pick and place machine
area.
Vision system pick and place machine NeoDen4, with high speed and accuracy, compact in body, low power,
stable quality and easy operation. It adopts our newly developed feeding system which can help to replace the
tape easily and install smoothly, together with its vision system and rails feeding system, committed to create
the great value for customers in actual PCB production.
NeoDen4, the 4th generation pick and place machine of NeoDen Tech, was independently designed and
developed with patents and CE certificate.
This machine is adopted dual cameras, four heads, auto rails, electronic feeder, two conveyor ports, which
achieves high accuracy, simple structure, stable performance and easy operation.
This manual cover installation, setup, customization and operation of the NeoDen4 pick and place machine.
Please read this manual in its entirety before working on the machine.
Populating PCBs with surface mount technology (SMT) can be as challenging as the circuit design itself, and
the NeoDen4 provides the user with all the tools necessary to work with a wide variety of components in a
wide variety of packaging. The NeoDen4 is not a knock-off. It is an original design that has been engineered
from the ground-up to provide simple, precise and flexible pick-and-place functionality. It is ideal for
prototyping and small runs, but is equally up to the task of producing large quantities of boards: the PCBs in
all NeoDen machines are made using a single NeoDen4. At NeoDen own factory, NeoDen mills own
precision metal parts, winds own motors for the feeders and peelers, writes own proprietary software and
assembles machines covered by over 50 patents. With ISO 9001 certification in pick-and-place quality control,
NeoDen rigorously tests each machine for days before shipping.
1
Number of Heads with
4
2
Placement Rate (under
factory test condition)
WITH VISION:5000/WITHOUT VISION:10000
3
Feeder capacity
TAPE REEL FEEDERS:48（all 8mm)
VIBRATING FEEDERS:5
4
IC tray capacity
5
5
Component sizes with
vision
Smallest Component size:0201
Largest Component size: TQFP240
6
Component Max Height
5MM
7
Resolution
X/Y axis:0.01MM Z axis:0.1MM
8
Rotation
+/-180°(360°)
9
Positioning Accuracy
+/-0.02MM
10
X-Y repeatability
+/-0.02MM
11
Placement Area
Without waffle Tray:290*1500MM
With 1 waffle Tray:140*1500MM
12
Main Control
GUI
13
Power Supply
110V/220V
14
Power
180W
2
1.2
Structure of NeoDen4
Design principles:
At the core, the NeoDen4 is a 4-axis Windows- controlled CNC with four separate vacuum nozzles,
each connected to its own vacuum pump. The machine employs a single X-Y coordinate system
covering the entire movement range of the head, which is 310x500mm. With resolution of .01mm
(10µm) and repeatability of .02mm (20µm), any X -Y coordinate can be identified as the location of a
feeder, the start of an array of components in a tray or short tape, a fiducial or the location at which a
component is to be placed on a circuit board.
Feeders and Nozzles:
Electric tape-and-reel feeders, vibration feeders and virtual tray feeders are all supported. Because of
the flexibility of the architecture, and the need to work with affordable quantities of parts, short tapes
can also be configured on the machine’s bed. Any size nozzle can be installed in any of the four
locations in the head, so a single machine can handle all of the necessary components without the
need for nozzle changes. The spring-loaded nozzles simply snap in and pull out of the head. Any
nozzle can be installed in any of the four locations on the head.
Number of Feeders:
The NeoDen4 can accommodate up to 48 8mm tape-and-reel feeders on its left and right rails, and
any size feeder (8, 12, 16 and 24mm) can be installed in any combination or order on the left and
right sides of the machine. The electric feeders are inexpensive but sophisticated microprocessor-
controlled units paired will tape peelers. In addition, the vibration feeder (included) can handle up to
5 separate tubes. The amount of space available for tray-fed components and short tapes depends on
the available real estate on the table. Any area of the table may be used for components awaiting
placement, or for the board under manufacture.
Component Thickness Limitations:
When using tray-fed and short-tape components, the maximum allowable component height is 5mm.
When using tape-and-reel components, we recommend a maximum thickness of 1.8mm for reliable
operation.
Rail system:
Machines equipped with the auto-loading rail system can accommodate boards from to in width, and
in length. Even when the rail system is installed, any space left over on the table is still available for
trays and short tapes. (The left rail can be moved to accommodate wide boards by removing the left
table extension. In this case, a block of material should be affixed to the table base to raise the tray or
short tape to the approximate height of the extension). The rail system allows automatic feeding of
PCBs, automatic alignment of the board with the camera, and automatic ejection from the front of the
machine or the rear. Rear-ejection is useful when the machine is connected to an optional conveyor
that can deliver the finished board directly to the reflow oven or to another NeoDen4.
Vision System:
The NeoDen4 features a high-precision, two-camera vision system. The cameras are made by Micron
Technology and are precisely aligned to the nozzles using the single unified configuration/operation
application that loads on power-on.
The downward-looking camera:
On the head is used for precision location of feeders and PCB placement points. The downward-
looking camera also verifies proper board placement (and compensates for minor board-position
inaccuracies) by auto-aligning the nozzles to multiple fiducials on the board before beginning actual
pick-and-place operations. Once the coordinates are established, the semi-closed-loop stepper motors
are able to repeat these locations to 20µm accuracy without further need for this camera.
The upward-looking camera：
located on the right side of the machine. When enabled, this camera first ensures that a component is
attached to the proper nozzle. If the camera detects the absence of a component, the machine will
make up to two additional attempts to pick a component before asking the user for further
instructions. Once a component has been verified as “picked”, the camera verifies its position relative
to the nozzle. Because SMDs are small and light, and are held only loosely in their packaging, there
can be a great deal of variation in the actual position of the component when it arrives in “pick”
position and is lifted by the nozzle. The vision system computes the difference between the ideal and
actual position (both X-Y and rotational), and then corrects for any error before precisely placing the
component. Because the vision system continually corrects for even small errors in component
