Introduction
1.2.5 Release History Other Instructions
Service Manual SIPLACE Glue Feeder 7
1.2.4.2
1.2.4.2 Important Measures to Protect Against Static Charging
Important Measures to Protect Against Static Charging
► Most plastics can easily become charged and must therefore be kept away from at-risk components.
► Always ensure that people, the workplace and packaging are safely earthed when handling electro
-
static sensitive components.
1.2.4.3
1.2.4.3 Handling ESD Modules
Handling ESD Modules
Do not touch electronic modules unless it is absolutely essential to do so in order to carry out other work.
If it is necessary, make sure that you do not touch the pins or printed conductors when you pick up flat
modules.
Do not touch components unless
▪ You are constantly earthed by an ESD wrist strap or
▪ You are wearing ESD shoes or ESD shoe earthing strips on an ESD floor.
Always discharge yourself before you touch an electronic module. To do this, simply touch a conductive
and earthed object immediately before you touch the module (such as unpainted parts of a switch cab
-
inet, a water pipe, etc.).
Do not allow modules with chargeable and highly insulating materials to touch one another, e.g. plastic
films, insulating table surfaces or items of clothing made from synthetic fibers.
Always place the modules on a conductive surface (table with an ESD coating, conductive ESD foam,
ESD bag or container).
Do not bring modules near visual display units, monitors or televisions. Keep them at least 10 cm away
from the screen.
1.2.4.4
1.2.4.4 Measurements and Modifications to ESD Modules
Measurements and Modifications to ESD Modules
Measurements of the assemblies may only be taken if
▪ The measuring device has been grounded (e.g. via protective conductor) or
▪ The measuring head of the potential-free measuring device has been briefly discharged before
measurement (e.g. touching blank metal control unit housing).
► Always use an earthed soldering iron if you carry out any soldering work.
1.2.4.5
1.2.4.5 Dispatching ESD Modules
Dispatching ESD Modules
► Always store modules and components in conductive packaging (e.g. metallized plastic bags or met
-
al sleeves) and dispatch them in conductive packaging.
► If the packaging is not conductive, place the modules in a conductive envelope before packaging.
Use conductive foam rubber, ESD bags, domestic aluminum foil or paper, for example. NEVER use
plastic bags or film.
► If the module has integral batteries, ensure that the conductive packaging does not touch or short-
circuit the battery terminals and, if necessary, first cover the terminals with insulating tape or mate
-
rial.
1.2.5
1.2.5 Release History
Release History
Changes
07/2012 First edition
12/2012 Updated new version
Introduction
Staff Qualifications and Training 1.2.6 SIPLACE on the World Wide Web (WWW)
8 Service Manual SIPLACE Glue Feeder
1.2.6
1.2.6 SIPLACE on the World Wide Web (WWW)
SIPLACE on the World Wide Web (WWW)
Log into our SIPLACE
®
homepage at http://www.siplace.com.
► You can choose between the German and English versions.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the
SIPLACE User Group
. Here you can call up spe
-
cial information about our placement systems e.g.
▪ Technical documentation,
▪ Technical information,
▪ Spare parts lists etc.
Registration for the user group is very simple:
► Click on the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.3
1.3 Staff Qualifications and Training
Staff Qualifications and Training
Qualified or adequately trained personnel means that these people are familiar with the setting up, op
-
eration and maintenance of automatic placement systems and add-on devices and are suitably qualified,
e.g.:
▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical
circuits and system components in accordance with normal safety standards.
▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord
-
ance with normal safety standards.
▪ Have received first aid training.
Overview
Service Manual SIPLACE Glue Feeder 9
2
2 Overview
Overview
Overview of spare parts
Spare part Item no.
1 Coupler plug KK3P-06E 03093200- xx
2 Manometer 4K8-4P assembly. (cartridge) 03094560- xx
3 Manometer 4K8-10P assembly. (dispenser) 03094559- xx
4 Handle assembly X12/X16 V2 03082057- xx
5 Cartridge holder assembly 03094060- xx
6 Cartridge Pipe 03089046- xx
7 Nozzle heating 03096486- xx
8 Flat nozzle FD6100 03094220- xx
9 Spare fluidic (jet block) 03094177- xx
10 Jet valve P-DOT (jet valve) 03096487- xx
11 EDIF secondary assembly X2x8 03065209- xx
12 Sliding foil, X-feeder JUM-S-06LY 03019604- xx
13 Plug-in fitting SCN-PK-4 03095834- xx
14 Pressure control valve LR-M7-D-O-MICRO-B assembly (cartridge) 03094558- xx
15 Pressure control valve LR-M7-D-O-7 assembly (dispenser) 03097857- xx
16 Regulator holder assembly 03097710- xx
17 Sliding guide/rear L200 03003994- xx
18 Solenoid valve assembly 03096565- xx
