4OM-1610 2-4 2. Management Information : Chap.2 2.2 Management Information List Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Informa…
4OM-1610
2-3
2. Management Informatio : Chap.2
0911-001
•
Remedial Procedure from “Management Information” Window
(1) Make a note of the management information.
Notice
If you forget the Management Information, correct recovery can not be
performed. Therefore, make sure to make a note.
(2) Press the [OK] button to return the original window.
(3) Perform the correct recovery based on the Management Information.
4OM-1610
2-4
2. Management Information : Chap.2
2.2 Management Information List
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
010101 Emergency Stop
Press [POWER ON] button to activate Load Power circuit.
010103 Emergency Stop
Emergency Stop switch is pressed. Please cancel it.
010201 Air Pressure Drop
Detection of Air Pressure Drop is detected
010401 Safety cover lock conrm
Please close and lock the safety cover.
010402 Safety cover lock conrm
Operate after close and lock the safety cover. (LED on)
010403 Safety cover lock conrm
Operate after close and lock the safety cover.
010503 Beam XY main loop OFF
Beam XY main circuit Error
010801 Feeder base conrm (Rear)
Set the feeder cart (rear) and connect cable.
010802 Feeder base conrm (Rear)
Detect elevator unit (rear).Operate after remove elevator .
010803 Feeder base conrm (Rear)
Could not detect elevator unit (rear). Connect elevator unit and operate by "unit
exchange menu".
010804 Feeder base conrm (Rear)
Disconnect elevator unit (rear). Check connector.
010805 Feeder base conrm (Rear)
Feeder cart (rear) is not upper position. Push feeder ready sw.
010806 Feeder base conrm (Rear)
Push feeder ready sw.
010807 Feeder base conrm (Rear)
Feeder base power or Feeder power is "OFF". Please press "Feeder Ready"
switch(Rear), and put it up again after putting Feeder Cart(Rear) down.
010901 Feeder base conrm (Front)
Set the feeder cart (front) and connect cable.
010902 Feeder base conrm (Front)
Detect elevator unit (front).Operate after remove elevator .
010903 Feeder base conrm (Front)
Could not detect elevator unit (front). Connect elevator unit and operate by "unit
exchange menu".
010904 Feeder base conrm (Front)
Disconnect elevator unit (front). Check connector.
010905 Feeder base conrm (Front)
Feeder cart (front) is not upper position. Push feeder ready sw.
010906 Feeder base conrm (Front)
Push feeder ready sw.
0911-001
4OM-1610
2-5
2. Management Informatio : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
010907 Feeder base conrm (Front)
Feeder base power or Feeder power is "OFF". Please press "Feeder Ready"
switch(Front), and put it up again after putting Feeder Cart(Front) down.
011001 Empty Feeder (rear)
Please set the feeder (rear) that used by the pattern program.
011101 Empty Feeder (front)
Please set the feeder (front) that used by the pattern program.
010b01 Feeder is not ready (rear)
Please turn on the Feeder Ready SW (rear).
010c01 Feeder is not ready (front)
Please turn on the Feeder Ready SW (front).
010d01 Pattern program is abnormal
Please set the normal pattern program
010e01 Prod Chng is not ready
Conveyor width does not t production data.
Execute conveyor width setup.
011401 Zeroing not nish
Perform All zeroing
011402 Zeroing not nish
Perform All zeroing
011403 Zeroing not nish
Perform All zeroing
011404 Zeroing not nish
Perform All zeroing
011405 Zeroing not nish
Perform All zeroing
011406 Motor is not servo on
Perform All zeroing
011701 P.C.B. position
Please position the P.C.B.
011702 P.C.B. position
Set the P.C.B. lower side position.
011703 P.C.B. position
Set the P.C.B. upper side position.
011704 P.C.B. position
Execute P.C.B. position cancel after cancelling operation.
011705 P.C.B. position
Please position P.C.B. [Input or Output] of [Lane A]
011706 P.C.B. position
Please position P.C.B. [Output position] of [Lane A].
011707 P.C.B. position
Please position P.C.B. [Input position] of [Lane A].
011708 P.C.B. position
Please position P.C.B. [Input or Output] of [Lane B].
011709 P.C.B. position
Please position P.C.B. [Output position] of [Lane B].
