4OM-1610
3-48
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indenite P.C.B. on Input position stop sensor.
Please remove P.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after starting.
There is an indenite P.C.B. on Input position decelerating sensor. Please remove
P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after starting.
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
426107 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indenite P.C.B. on Input position stop sensor.
Please remove P.C.B..
426108 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
There is an indenite P.C.B. on Output position decelerating sensor.
Please remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
There is an indenite P.C.B. on Output position stop sensor.
Please remove P.C.B..
4OM-1610
3-49
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
42610c Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610d Detection of positioning conveyor sensor
Decrease sensor of output position was detected after starting.
There is an indenite P.C.B. on Output position stop sensor.
Please remove P.C.B..
42610e Detection of positioning conveyor sensor
Decrease sensor of output position was not detected after starting.
-----
42610f Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
There is an indenite P.C.B. on Output position stop sensor.
Please remove P.C.B..
426110 Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
426111 Detection of positioning conveyor sensor
P.C.B. on positioning conveyor was detected
Please remove P.C.B. from positioning conveyor.
426112 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
Conrm whether P.C.B. is not dropping.
Conrm whether Sensor is not broken.
426201 positioning conveyor timeout
Placement for input position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input conveyor to Input
position or is dropped. Please conrm from Input to positioning conveyor.
426202 positioning conveyor timeout
Output from input position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input position to Output or is
dropped.
Please conrm from positioning to Output conveyor.
426203 positioning conveyor timeout
Placement for output position was not completed within predetermined time.
P.C.B. inserted is place in Output position.
There is a possibility of it fallen. Please conrm from Input to Positioning conveyor.
426204 positioning conveyor timeout
Output from output position was not completed within predetermined time.
There is a possibility whether P.C.B. is placed from Input position to Output or is
dropped.
Please conrm from positioning to Output conveyor.
4OM-1610
3-50
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
426301 positioning conveyor Error
Error in positioning conveyor
-----
427101 Detection of Output conveyor sensor
Decrease sensor was detected before starting.
There is an indenite P.C.B. on Output conveyor.
Please remove it.
427102 Detection of Output conveyor sensor
Decrease sensor was not detected before starting the movement
P.C.B. to output is not found
1. Please put P.C.B. on Sensor.
2. There is a possibility of P.C.B. fallen. Conrm the conveyor width.
427103 Detection of Output conveyor sensor
Stop sensor was detected before starting.
There is an indenite P.C.B.. Please remove it.
427104 Detection of Output conveyor sensor
Stop sensor was not detected before starting.
Cannot nd P.C.B. to output.
1. Is P.C.B. detected by sensor?
2. There is a possibility that P.C.B. is falling. Please check the width of conveyor.
427105 Detection of Output conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
There is an indenite P.C.B. on Output conveyor. Please remove it.
427106 Detection of Output conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
427107 Detection of Output conveyor sensor
P.C.B. on stop sensor was detected after movement completion
There is an indenite P.C.B. on Output conveyor. Please remove it.
427108 Detection of Output conveyor sensor
P.C.B. on stop sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
427109 Detection of Output conveyor sensor
P.C.B. on output conveyor was detected
Please remove P.C.B. from the conveyor
42710a Detection of Output conveyor sensor
P.C.B. on output conveyor was not detected
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
42710b Detection of Output conveyor sensor
Stop sensor is not passed during Output operation
The conveyor is stopped before P.C.B. goes through Sensor.
1. Conrm output method, transition speed, timer setting.
2. Check the connected cable.
