4OM-1610
2-11
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018309 Multi-tray (Front)
Zeroing of Elevator1-axis is not nished. Perform zeroing of multi-tray.
01830a Multi-tray (Front)
Zeroing of Elevator2-axis is not nished. Perform zeroing of multi-tray.
01830b Multi-tray (Front)
Pickup miss cmpnt(8mm) is detected.[B15417]
01830c Multi-tray (Front)
Pickup miss cmpnt(14mm) is detected.[B15418]
01830d Multi-tray (Front)
Pickup miss cmpnt(28mm) is detected.[B15419]
01830e Multi-tray (Front)
Pallet Chuck claw is open.
01830f Multi-tray (Front)
Pallet Flying away is detected.
018310 Multi-tray (Front)
Magazine1 (Lower) Shutter on Traverse side is open.
018311 Multi-tray (Front)
Magazine2 (Upper) Shutter on Traverse side is open.
018312 Multi-tray (Front)
Access detecting Sensor (Right) : Cannot detect Elevator Unit
018313 Multi-tray (Front)
Access detecting Sensor (Left) : Cannot detect Elevator Unit
018401 Multi-tray is not ready to zeroing(Rear)
Execute all zeroing.
018501 Multi-tray is not ready to zeroing(Front)
Execute all zeroing.
018601 Warning of wiring error
Vacuum Pump 1CB Error
018602 Warning of wiring error
Monitor Error of DC load power
018603 Warning of wiring error
Monitor Error of Beam(1) CB Error
018604 Warning of wiring error
Monitor Error of Beam(2) CB Error
018701 Feeder Alternate
Illegal alternate setup of pattern program. Check the setup.
018702 Feeder Alternate
Invalid feeder in alternating. Set feeder valid
018801 XY Origin Offset
Illegal XY-Origin offset of Beam(Rear). Re-send Device data from NT, or execute
teaching XY-Origin offset.
018802 XY Origin Offset
Illegal XY-Origin offset of Beam(Front). Re-send Device data from NT, or execute
teaching XY-Origin offset.
018901 Feeder communication
Feeder(Rear) is on communication. Please wait for it, and then operate again.
0911-001
4OM-1610
2-12
3. Machine Information : Chap.2
0911-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
018902 Feeder communication
Feeder(Front) is on communication. Please wait for it, and then operate again.
018a01 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Rear)
018a02 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.(Front)
018b01 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Rear)
018b02 Library Tape Width check
Library Tape Width differs from Feeder. Please check Library and Feeder.(Front)
019001 Support Pin
Please move exchange position of support pin.
019002 Support Pin
Noz for enchasing support pin is not set, or Odd-shape noz is set.
019003 Support Pin
Placement data in current differs from it of Support Pin of current pattern program.
Please set-up the support pin.
030162 Operation Requirement
The pattern cannot be switched
030416 Operation Requirement
ACV server does not pass the authorization. Please retry connection to server on
a screen [UNIT ADJ]-[ACV Set].
03041C Operation Requirement
ACV Check Error. Component ID on the feeder is not same as one specied by
current program.
030430 Operation Requirement
Can not detect Feeder cart(Rear). Please set Feeder cart to the inside.[B0910,
B0911]
030420 Operation Requirement
Communications with the ACV server is impossible. After conrming the ACV
server, please try to perform it again in the tab sheet: [MAINT]-[UNIT ADJ]-[ACV
ADJ].
030431 Operation Requirement
Can not detect Feeder cart(Front). Please set Feeder cart to the inside.[B0910,
B0911]
030432 Operation Requirement
The connector of the feeder base (rear) is not connected to the main body, so
please connect it. [B0916]
030433 Operation Requirement
The connector of the feeder base (front) is not connected to the main body, so
please connect it. [B0916]
030440 The Safety cover is open. Please close it. (Caution : Stage Ready cannot be ON
by manual operation because of no Cart)
030441 Operation Requirement
It is impossible to do pass operation without Cart because func of Traceability is
valid. Please restart after setting Option invalid.
4OM-1610
2-13
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030442 Operation Requirement
It cannot move because a simple Cover locked. First, set Stage ready OFF, then
set Stage ready ON.
030501 Misidentication a type of multi-tray
The connected Tray unit(Rear) doesn't match setup of Device. Please conrm a
type of tray unit, set it on unit exchange screen later.
030502 Misidentication a type of multi-tray
The connected Tray unit(Front) doesn't match setup of Device. Please conrm a
type of tray unit, set it on Unit Exchange Screen later.
030601 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Rear) on Unit exchange Screen.
030602 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Front) on Unit exchange Screen.
030603 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Rear).
030604 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Front).
050201 Conrmation of P.C.B. existence
Remove P.C.B. from Conveyor
050202 Conrmation of P.C.B. existence
P.C.B. is detected from Input position because Finish mode is set [Output]. Please
P.C.B. from conveyor.
050203 Conrmation of P.C.B. existence
P.C.B. is detected from Output position because Finish mode is set [Input]. Please
P.C.B. from conveyor.
050204 Conrmation of P.C.B. existence
P.C.B. was detected from Inlet sensor of input conveyor. Please remove P.C.B.
050205 Conrmation of P.C.B. existence
The operation mode of Lane A is set [STOP]. Please remove P.C.B. when not
transferred.
050206 Conrmation of P.C.B. existence
The operation mode of Lane B is set [STOP]. Please remove P.C.B. when not
transferred.
050301 Conrmation of Firmware version
Firmware of transfer driver is not the latest version. Please update it with the latest
version.
050401 Manual transfer
P.C.B. (X>260mm) which is set by PP data is unable to take Input Position.
050402 Manual transfer
Please operate after removing P.C.B. from output conveyor. There is a possibility
of pushing and rising with Stopper.
