4OM-1610
2-19
4. "Error" Window : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
801101 Nozzle diameter conrmation
The disagreement of the nozzle diameter was detected with the linear measure.
There is a possibility of the linear measure dirt and the nozzle dirt, please conrm
whether a different nozzle has adhered.
-----
801b01 Lightning Surge alarm
Lightning Surge Protector works; Q204.
-----
801b02 Lightning Surge alarm
Lightning Surge Protector works; Q204. Running continue.
-----
801b03 Lightning Surge alarm
Protective Fuse error of lightning Surge Protector. Exchange the fuse.
-----
801c05 Information
Warm start mode was canceled.
-----
801c06 Information
The machine stopped by the automatic stop function.
-----
802001 Alarm for Splicing
The feeder is running short of the component to feed. Please prepare for Splicing,
and remove the cover tape from the storage section.
-----
802101 Feeder Maintenance alarm
The total number of feeder's shots reached a previous notice setting number.
-----
802102 Feeder Maintenance alarm
The feeder adsorption rate decreased and exceeded the previous notice setting
number.
-----
802301 Splicing No Check Alarm
The seam passed the detection sensor as unregistered splicing. Please register
the splicing.
-----
802401 Feeder Cover Tape lled up alarm
The storage section of Cover Tape lled was detected. Please remove Tape from
internal storage section.
-----
802501 Feeder Communication Error
Failed to displaying Operational Panel. Please put the Cart down, or pull out and
insert Feeder.
-----
802502 Feeder Communication Error
The communication processing of Feeder was not done in prescribed time.
-----
0911-001
4OM-1610
2-20
4. "Error" Window : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
803028 FAN Stop alarm
Fan rotation error of Control Box. Clean up Fan.
-----
809201 Library tape width check
The tape width in library and the feeder are not in agreement. Please check the
library and feeder.
-----
809301 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
809c01 Motor system error
Communication not establish with Servo Amp (XY Beam).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809c02 Motor system error
Servo parameter error. (0x21E)
-----
809c03 Motor system error
Communication not establish with Servo Amp (Head).
Check following
1. Rotary sw of Servo Amp.
2. Condition of AC power.
3. Communication cable.
809d01 Recycle conveyor lled up
Recycle conveyor became Full. (Rear)
-----
809d02 Recycle conveyor lled up
Recycle conveyor became Full. (Front)
-----
809e01 Automatic Teaching
Please skip it because Automatic modication Teaching is impossible in Nozzle
position of Rear Head.
-----
809e02 Automatic Teaching
Please skip it because Automatic modication Teaching is impossible in Nozzle
position of Rear Head.
-----
809f01 Automatic Teaching
There is no magazine. Magazine 1 (Lower).
-----
809f02 Automatic Teaching
Rack shutter of operator side is open. Magazine 1 (Lower)
-----
0911-001
4OM-1610
2-21
4. "Error" Window : Chap.2
Machine
Information Code
Display Area A (The outline of the Machine Information)
Display Area B (The details of the Machine Information)
809f03 Automatic Teaching
Rack shutter of traverse side is open. Magazine 1 (Lower)
-----
809f04 Automatic Teaching
The Magazine is not set correctly. Magazine 1 (Lower)
Check lock lever of magazine.
-----
809f05 Automatic Teaching
There is no magazine. Magazine 2 (Upper).
-----
809f06 Automatic Teaching
Rack shutter of operator side is open. Magazine 2 (Upper)
-----
809f07 Automatic Teaching
Rack shutter of traverse side is open. Magazine 2 (Upper)
-----
809f08 Automatic Teaching
The Magazine is not set correctly. Magazine 2 (Upper)
Check lock lever of magazine.
-----
809f09 Automatic Teaching
Motor Error of Magazine(Lower) is detected.
-----
809f0a Automatic Teaching
Motor Error of Magazine(Upper) is detected.
-----
80a001 Recognition Error
Failed in the recognition of the part. Please retry pickup of the part.
-----
80a002 Recognition Error
Nozzle position teaching failure.
Check nozzle condition.
-----
80a101 Reading the Linear measure sensor Version
The operation for turning on is invalid. Please do operation again after turning on
completely.
-----
80b001 Automatic Teaching Error
Failed in the recognition. Carr it out again on the next time.
-----
80c001 Multi-layered Tray turning on
Failed in turning on Driver power of Tray(Rear) Magazine1(Lower).Please conrm
the wiring of Machine
-----
