4OM-1610
3-3
3. Error IDs and Remedial Procedures : Chap.3
0911-001
3. Error IDs and Remedial Procedures
3.1 Safety Device
Error ID Error Name, Description, Cause, and Remedy
400101 Load Power Shutoff
The [emergency stop] switch was pressed. (Please conrm the nozzle has not
fallen when you push the beam by the hand.)
Please switch on a power supply after canceling an emergency stop switch and
screen return to normal display.
400102 Load Power Shutoff
An emergency stop switch is pushed.
Please switch on a power supply after canceling an emergency stop switch and
screen return to normal display.
400301 Zeroing Error.
Abnormality was found in processing zeroing operation.
Please perform zeroing.
400401 Interlock Error
The [emergency stop] switch was pressed. (Please conrm the nozzle has not
fallen when you push the beam by the hand.)
Please switch on a power supply after canceling an emergency stop switch and
screen return to normal display.
400402 Interlock Error
The safety cover opened. [K4]
Please shut a safety cover and push the [POWER ON] button.
400403 Interlock Error
The main circuit of the XY Beam was broken. [K**]
-----
400404 Interlock Error
Head (Rear) nozzle descent was detected. [A-B****]
Please perform a zeroing.
400405 Interlock Error
Head (Front) nozzle descent was detected. [B-B****]
Please perform a zeroing.
400406 Interlock Error
Head (Rear) descent was detected. [A-B****]
Please perform a zeroing.
400407 Interlock Error
Head (Front) descent was detected. [B-B****]
Please perform a zeroing.
400408 Interlock Error
A pickup-failed component (Rear) was detected. [DA-B****]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
4OM-1610
3-4
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
400409 Interlock Error
A pickup-failed component (Front) was detected. [DB-B****]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
40040A Interlock Error
The feeder opening sensor (Rear) was shaded. [B****]
Please remove the factor which is shading the feeder opening sensor (rear), and
carry out zero return.
40040B Interlock Error
The feeder opening sensor (Front) was shaded. [B****]
Please remove the factor which is shading the feeder opening sensor (front), and
carry out zero return.
40040C Interlock Error
Disengaged Latch(Rear) was detected.
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
40040D Interlock Error
Disengaged Latch(Front) was detected.
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
40040E Interlock Error
The safety cover lock was released.
Close the safety cover and lock it.
40040F Interlock Error
Head (Rear) interlock was detected.
Please perform a zeroing.
400410 Interlock Error
Head (Front) interlock was detected.
Please perform a zeroing.
400411 Interlock Error
Air pressure down was detected.
Check air pipe came off or bend, air compressor.
400412 Interlock Error
Circuit breaker of Vacuum pomp was tripped.
Check vacuum pump and wiring.
400413 Interlock Error
Circuit breaker of XY Beam (Rear) was tripped.
Check servo amplier and cables.
400414 Interlock Error
Circuit breaker of XY Beam (Front) was tripped.
Check servo amplier and cables.
400415 Interlock Error
Over squeeze1 detected (Rear)[B05]
-----
4OM-1610
3-5
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
400416 Interlock Error
Over squeeze2 detected (Rear)[B05]
-----
400417 Interlock Error
Over squeeze3 detected (Rear)[B05]
-----
400418 Interlock Error
Pass level 1 error (Rear) detected[B04]
-----
400419 Interlock Error
Pass level 2 error (Rear) detected[B04]
-----
40041a Interlock Error
Pass level 3 error (Rear) detected[B04]
-----
40041b Interlock Error
Nozzle oat up 1 (Rear) detected[B1611]
Conrm Nozzle of Nozzle Stocker1(Rear).
40041c Interlock Error
Nozzle oat up 2 (Rear) detected[B1611]
Conrm Nozzle of Nozzle Stocker2(Rear).
40041d Interlock Error
Over squeeze1 detected (Front)[B05]
-----
40041e Interlock Error
Over squeeze2 detected (Front)[B05]
-----
40041f Interlock Error
Over squeeze3 detected (Front)[B05]
-----
400420 Interlock Error
Pass level 1 error (Front) detected[B04]
-----
400421 Interlock Error
Pass level 2 error (Front) detected[B04]
-----
400422 Interlock Error
Pass level 3 error (Front) detected[B04]
-----
400423 Interlock Error
Nozzle oat up 1 (Front) detected[B1611]
Conrm Nozzle of Nozzle Stocker1(Front).
400424 Interlock Error
Nozzle oat up 2 (Front) detected[B1611]
Conrm Nozzle of Nozzle Stocker2(Front).
