4OM-1610 3-86 3. Error IDs and Remedial Procedures : Chap.3 091 1-001 3.9 Handling Error Error ID Error Name, Description, Cause, and Remedy 500101 Comp. Missing (Sensor) Comp. Missing (Sensor) There is a possibility tha…

4OM-1610

3-85

3. Error IDs and Remedial Procedures : Chap.3

Error ID Error Name, Description, Cause, and Remedy

4b4201 Feeder Alarm

Alarm Code:E2 - Origin Position Checking Error (Excessively out of the origin

during servo ON)

If the error occurs frequently, replace the feeder. (It may be caused by trouble of

the control P.C.B..)

4b4202 Feeder Alarm

Alarm Code:E4 - Positioning Completion Timeout (Foreign substances in the

sprocket wheel)

Conrm whether or not the tape is being jammed on the path./ Conrm the reel to

operate smoothly./ Conrm whether or not some components and dust are being

caught in the sprocket.

4b4203 Feeder Alarm

Alarm Code:E6 - Lane Change Timeout Error

If the error occurs frequently, replace the feeder. (It may be caused by trouble of

the control P.C.B..)

4b4204 Feeder Alarm

Alarm Code:E7 - Servo ON Timeout

If the error occurs frequently, replace the feeder. (It may be caused by trouble of

the control P.C.B..)

4b4205 Feeder Alarm

Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)

Conrm whether or not the tape is being jammed on the path./ Conrm the reel to

operate smoothly./ Conrm whether or not some components and dust are being

caught in the sprocket./ Conrm whether or not some components and dust are

being caught in the tape feeding gear.

4b4301 Feeder Section(Miss-pickup)

A pickup error occurred due to feeder operation problem. Please check the feeder

and the component.

-----

4b4401 Error in conrming connection of Feeder

Error in conrming connection of Feeder

Please check connection of Feeder

4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)

Cannot send Tape because alarm is found in one side Lane of Dual Feeder.

Please execute recovery process, and then operate it again.

4b4601 Feeder error (feeding time-out)

Feeder error (feeding time-out)

----

T4C10

0911-001

4OM-1610

3-86

3. Error IDs and Remedial Procedures : Chap.3

0911-001

3.9 Handling Error

Error ID Error Name, Description, Cause, and Remedy

500101 Comp. Missing (Sensor)

Comp. Missing (Sensor)

There is a possibility that the picked comps. have fallen on the feeder and please

conrm it.

500301 Comp. Missing (Recog)

Comp. Missing (Recog)

There is a possibility that the picked comps. have fallen on the feeder and please

conrm it.

500401 Comp. Recog Error

Comp. Recog Error

-----

500501 Shortage of Component

Shortage of Component

-----

500502 Feeder Reload Stop

Feeder Reload Stop (Splicing)

-----

500c01 Comp. Vertical(Sensor)

Comp. Vertical(Sensor)

-----

500f01 Comp. Thickness(Sensor)

Comp. Thickness(Sensor)

-----

T4C11

4OM-1610

3-87

3. Error IDs and Remedial Procedures : Chap.3

0911-001

3.10 Automatic Operation Error

Error ID Error Name, Description, Cause, and Remedy

510a01 Feeder Pocket recog Error

Abnormality occurred in process of recognizing Feeder Pocket.

-----

510b01 Auto Run Error

Master bad mark detection is abnormal.

-----

510b02 Auto Run Error

Bad mark detection is abnormal.

-----

510e01 Nozzle air blow Error(Rear)
