4OM-1610
3-54
3. Error IDs and Remedial Procedures : Chap.3
0911-001
3.5 PEC Recognition
Error ID Error Name, Description, Cause, and Remedy
460101 P.E.C. Inspection
P.E.C. Mark #1 (Global)
-----
460102 P.E.C. Inspection
P.E.C. Mark #2 (Global)
-----
460103 P.E.C. Inspection
P.E.C. Mark #3 (Global)
-----
460104 P.E.C. Inspection
P.E.C. Mark #1 (Image)
-----
460105 P.E.C. Inspection
P.E.C. Mark #2 (Image)
-----
460106 P.E.C. Inspection
P.E.C. Mark #3 (Image)
-----
460107 P.E.C. Inspection
P.E.C. Mark #1 (Local)
-----
460108 P.E.C. Inspection
P.E.C. Mark #2 (Local)
-----
460109 P.E.C. Inspection
P.E.C. Mark #3 (Local)
-----
46010a P.E.C. Inspection
Land P.E.C. Mark #1
-----
46010b P.E.C. Inspection
Land P.E.C. Mark #2
-----
46010c P.E.C. Inspection
Land P.E.C. Mark #3
-----
46010d P.E.C. Inspection
Failed in P.E.C. Recognition
Please perform to the following
1. Repeat P.C.B. positioning
2. Conrm whether the Mark position of P.C.B. Recognition is correct.
T4C7
4OM-1610
3-55
3. Error IDs and Remedial Procedures : Chap.3
0911-001
3.6 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
490603 Conveyor Width Automatic Adjustment
PCB exists on the L conveyor.
-----
490604 Conveyor Width Automatic Adjustment
PCB exists on the R conveyor.
-----
490617 Conveyor Width Automatic Adjustment
Software limit
-----
490690 Conveyor Width Automatic Adjustment
Auto Setup Error(Others).
-----
490701 Nozzle set up
Nozzle Stocker is not set.
Please check whether it is correctly set to the stocker base.
490702 Nozzle set up
Motor Error Detection.
-----
490703 Nozzle set up
Nozzle Stocker Shutter open/close failed.
There is no float going up of a nozzle, or please check whether there is any
connection etc. in opening and closing.
490704 Nozzle set up
The up/down movement of Nozzle Stocker failed.
Please conrm whether Upper/Lower Cylinder has no error.
490705 Nozzle set up
Nozzle placing was not found in the stocker.
Check whether there is any difference in stocker arrangement data and real
arrangement.
490707 Nozzle set up
There is no free space for nozzle storing. Please conrm the arrangement data.
Please conrm the Stocker arrangement data.
490708 Nozzle set up
There are neither a free space nor a nozzle for nozzle exchange.
Please set up an insufcient nozzle in Nozzle stocker.
490709 Nozzle set up
Nozzle exchange abnormal data was found.
Please conrm the nozzle arrangement and the Stocker arrangement data.
49070a Nozzle set up
Nozzle stocker position teaching failed.
Please teach the Nozzle stocker position again on the instruction screen.
49070c Nozzle set up
Nozzle level teach error Detection.
Please execute the nozzle level teaching again on the nozzle level teach screen,
and conrm there is no unexpected value.
4OM-1610
3-56
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
49070d Nozzle set up
It failed in the nozzle placement check. Conrm the recognition image and select
the nozzle existence.
Please select a recognition image and choose the existence of a nozzle.
49070e Nozzle set up
The remains nozzle was detected on the head. The nozzle cannot be set to this
position.
Please confirm the nozzle has not adhered to the position. Moreover, please
clean the linear measure when not adhering.
49070f Nozzle set up
Abnormal nozzle level detected. Possibilities are the nozzle was not fully inserted
in the head, or linear measure saw dust or scratch.
Please conrm whether the nozzle has adhered to the position.
490710 Nozzle set up
The receipt nozzle was undetectable on the head.
Please conrm whether the nozzle has adhered to the position.
490711 Nozzle set up
The remains nozzle was detected on the head.
Please conrm the nozzle has not adhered to the position.
Moreover, please clean the linear measure when not adhering.
490712 Nozzle set up
The linear measure error occurred in the head nozzle existence check.
Please conrm the nozzle arrangement, and execute the level teaching.
490713 Nozzle set up
The nozzle exchange sequence error occurred.
Please conrm the nozzle placement.
490716 Nozzle set up
Time-out of close nozzle stocker operation.
Nozzle stocker was opened for safety.
Please conrm whether there is no rise to the surface the nozzle is not in opening
and shutting caught state.
490722 Nozzle set up
An error occurred with the nozzle existence check in the stocker before the nozzle
is stored.
-----
490723 Nozzle set up
It failed in the nozzle storage check. Conrm the recognition image and select the
nozzle existence.
-----
490730 Nozzle set up
Error in calculating recognized position of Nozzle ID.(XY-axis)
-----
490731 Nozzle set up
Failed in starting XY-axis.
-----
