4OM-1610 3-103 3. Error IDs and Remedial Procedures : Chap.3 Error ID Error Name, Description, Cause, and Remedy 601f0a NL Axis offset teach T ime-out of DD/NS-axis movement ----- 601f0b NL Axis offset teach Error during…
4OM-1610
3-102
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
601a0c Linear measure sensor correction re-teach
Offset correction can not be completed. Please use the big nozzle(HA05) teach
again and adjust the light & receive optical Axis(Fail to save-Err17)
-----
601a0d Linear measure sensor correction re-teach
The measurement value of the nozzle is not within 0.2mm to 0.6mm.
Adjust the height of the linear measure sensor otherwise, replace it.
601a0e Linear measure sensor correction re-teach
The linear measure control has an error.(err2, err3)
All E/NR Error. There is a possibility that Light Emitter or Receiver is broken.
601a0f Linear measure sensor correction re-teach
The linear measure control has an error.(err1)
Could be P.C.B. Error
601a10 Linear measure sensor correction re-teach
The linear measure control has an error.(err4)
A quantity of light emitter is dropping. There is a possibility of Light Emitter broken.
601a11 Linear measure sensor correction re-teach
No strobe response
Please conrm the wiring of HLS. Either, conrm P.C.B. address.
601f01 NL Axis offset teach
Error before Line Sensor measurement began
-----
601f02 NL Axis offset teach
Error during Line Sensor measurement
-----
601f03 NL Axis offset teach
Error of NS-axis movement
-----
601f04 NL Axis offset teach
Error of DD-axis movement
-----
601f05 NL Axis offset teach
Error of NL-axis movement
-----
601f06 NL Axis offset teach
Error of DD/NS-axis movement
-----
601f07 NL Axis offset teach
Time-out when Line Sensor measurement began
-----
601f08 NL Axis offset teach
Read Time-out of Line Sensor measurement
-----
601f09 NL Axis offset teach
Time-out of NL-axis movement
-----
4OM-1610
3-103
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
601f0a NL Axis offset teach
Time-out of DD/NS-axis movement
-----
601f0b NL Axis offset teach
Error during Teach
-----
602001 Writing Line measure Sensor Program
Fail to write Line Sensor Program
-----
602101 Teaching Tray Pallet Transition
Elevator Check Error
-----
602102 Teaching Tray Pallet Transition
Error in Elevator axis movement position calculating
-----
602103 Teaching Tray Pallet Transition
Elevator axis Movement Error
-----
602104 Teaching Tray Pallet Transition
Time-out in elevator axis movement
-----
602105 Teaching Tray Pallet Transition
Elevator axis Movement Error
-----
602106 Teaching Tray Pallet Transition
Time-out in elevator axis movement
-----
602107 Teaching Tray Pallet Transition
Elevator axis Movement Error
-----
602108 Teaching Tray Pallet Transition
Error in elevator Stop Auto Run
-----
602109 Teaching Tray Pallet Transition
Time-out in elevator Stop Auto Run
-----
60210A Teaching Tray Pallet Transition
-----
-----
60210B Teaching Tray Pallet Transition
Program Error
-----
602201 Teaching Pulling Traverse
Pre-check error in driver-axis
-----
0911-001
4OM-1610
3-104
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
602202 Teaching Pulling Traverse
Elevator is not in Component Reload position
-----
602203 Teaching Pulling Traverse
L-axis/HL-axis is falling
-----
602204 Teaching Pulling Traverse
Traverse-axis Zeroing Error
-----
602205 Teaching Pulling Traverse
Traverse-axis Zeroing Time-out
-----
602206 Teaching Pulling Traverse
Pallet pulled out is detected during zeroing
-----
602207 Teaching Pulling Traverse
Error in Traverse-axis movement position calculating
-----
602208 Teaching Pulling Traverse
Traverse-axis Movement Error
-----
602209 Teaching Pulling Traverse
Traverse-axis Movement time-out
-----
60220a Teaching Pulling Traverse
Error in XY-axis movement position calculating(Pin Recog. Position)
-----
60220b Teaching Pulling Traverse
Error of XY-axis movement
-----
60220c Teaching Pulling Traverse
Time-out in XY-axis movement
-----
60220d Teaching Pulling Traverse
Error of P.C.B. Recognition Lamp On
-----
60220e Teaching Pulling Traverse
Time-out of P.C.B. Recognition Lamp On
-----
60220f Teaching Pulling Traverse
Image Capture Error
-----
602210 Teaching Pulling Traverse
Image Capture Time-out
-----
