4OM-1610
3-83
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3205 Servo Motor Error
Time-out of processing Servo On(Rear)
Please restart the machine.
4b3206 Servo Motor Error
Time-out of processing Servo On(Front)
Please restart the machine.
4b3301 Data Communication Error
failed in data expansion
There is a possibility of following errors
1. Communication Error
2. Data loss
Please contact the service when not repaired even if turns it on again.
4b3401 Nozzle check Error before Pickup(Detected before operating)
It stopped because the remains components on the nozzle or adhering matters
on the linear measure sensor of Light Emitter/Receiver were detected.
The remains Component on a nozzle or aw and soil on Light Emitter/Receiver of
Linear measure Sensor could be considered to adhere. Please clean it up.
4b3402 Nozzle check Error before Pickup(Detected before operating)
Error in Communication with Linear measure sensor.
Please conrm Error from Log Request Screen(Unit adjustment → Linear
measure Sensor Screen). Either, please conrm whether the items of LS-RLS-
S(Device Check → List) is Yellow. HLS communication cable could not be
connected and such like things.
4b3403 Nozzle check Error before Pickup(Detected before operating)
Error in Origin moving in HL/NL/L-axis
-----
4b3404 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up
-----
4b3405 Nozzle check Error before Pickup(Detected before operating)
Error in discarding the remains detect component
-----
4b3406 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up(program error)
-----
4b3501 Automatic Zeroing Error
Failed to zeroing automatically
Please restart.
4b3601 Receding Error
Motor Error on receding
-----
4b3602 Receding Error
Time-out on receding
-----
4b3701 Writing Origin position of License nozzle
Linear measure Sensor error is detected before operating.
-----
0911-001
4OM-1610
3-84
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3702 Writing Origin position of License nozzle
Failed in getting Offset data
-----
4b3703 Writing Origin position of License nozzle
Failing in writing origin position of Noz.
-----
4b3801 Bad Mark Sensor Error
Cannot detect Bad Mark normally for Error in Bad Mark Sensor.
Execute adjustment of Bad Mark Sensor
4b3901 Bad Mark Sensor Error
-----
4b3902 Bad Mark Sensor Error
-----
4b3903 Bad Mark Sensor Error
-----
4b3904 Bad Mark Sensor Error
-----
4b3905 Bad Mark Sensor Error
-----
4b3906 Bad Mark Sensor Error
-----
4b3907 Bad Mark Sensor Error
-----
4b3908 Bad Mark Sensor Error
-----
4b3909 Bad Mark Sensor Error
-----
4b390a Bad Mark Sensor Error
-----
4b390b Bad Mark Sensor Error
------
4b4001 Damaged cover tape / Cover tape jammed in the storage / Splicing section
peeling off
Alarm Code:E0 - (1)Damaged cover tape/ (2)Cover tape jammed in the storage/
(3)Splicing section peeling off
(1)Conrm whether or not the cover tape is set correctly/ (2) Please remove the
cover tape from the storage section./ (3) Please check the splicing condition if the
work performed correctly in the process.
4b4101 Cover tape peeling off error (Get caught up)
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
(1) Conrm whether or not the cover tape is set correctly./ (2)Conrm whether or
not some sticky material has adhered to the suppressor./ (3)Conrm the splicing
condition if the work performed correctly in the process.
0911-001
4OM-1610
3-85
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b4201 Feeder Alarm
Alarm Code:E2 - Origin Position Checking Error (Excessively out of the origin
during servo ON)
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b4202 Feeder Alarm
Alarm Code:E4 - Positioning Completion Timeout (Foreign substances in the
sprocket wheel)
Conrm whether or not the tape is being jammed on the path./ Conrm the reel to
operate smoothly./ Conrm whether or not some components and dust are being
caught in the sprocket.
4b4203 Feeder Alarm
Alarm Code:E6 - Lane Change Timeout Error
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b4204 Feeder Alarm
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder. (It may be caused by trouble of
the control P.C.B..)
4b4205 Feeder Alarm
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Conrm whether or not the tape is being jammed on the path./ Conrm the reel to
operate smoothly./ Conrm whether or not some components and dust are being
caught in the sprocket./ Conrm whether or not some components and dust are
being caught in the tape feeding gear.
4b4301 Feeder Section(Miss-pickup)
A pickup error occurred due to feeder operation problem. Please check the feeder
and the component.
-----
4b4401 Error in conrming connection of Feeder
Error in conrming connection of Feeder
Please check connection of Feeder
4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b4601 Feeder error (feeding time-out)
Feeder error (feeding time-out)
----
T4C10
