4OM-1610 3-83 3. Error IDs and Remedial Procedures : Chap.3 Error ID Error Name, Description, Cause, and Remedy 4b3205 Servo Motor Error T ime-out of processing Servo On(Rear) Please restart the machine. 4b3206 Servo Mot…
4OM-1610
3-82
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3104 Cutter(Servo Error)
Multi-rotation Error
Check motor wiring or exchange motor.
4b3105 Cutter(Servo Error)
The value of Deviation Counter was over the set value
Check the wiring of Origin sensor. Either, Exchange driver.
4b3106 Cutter(Servo Error)
Power Drive detected temperature error.
Ambient Temperature is too high. Exchange driver.
4b3107 Cutter(Servo Error)
Sensor Error
Conrm the wiring of Motor Encoder. Either, exchange motor
4b3108 Cutter(Servo Error)
High Drive voltage
Insufcient power capacity. Exchange driver.
4b3109 Cutter(Servo Error)
Low drive voltage
Please conrm the operating Power wiring which is inserted to driver.
4b310a Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310b Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310c Cutter(Servo Error)
CPU Error
Exchange Driver
4b310d Cutter(Servo Error)
Parameter Error
Please conrm the changed Parameter
4b310e Cutter(Servo Error)
Alarm code readout failed
-----
4b3201 Servo Motor Error
Error of processing Servo On
-----
4b3202 Servo Motor Error
Time-out of processing Servo On
-----
4b3203 Servo Motor Error
Error of processing Servo Off
-----
4b3204 Servo Motor Error
Time-out of processing Servo Off
-----
0911-001
4OM-1610
3-83
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3205 Servo Motor Error
Time-out of processing Servo On(Rear)
Please restart the machine.
4b3206 Servo Motor Error
Time-out of processing Servo On(Front)
Please restart the machine.
4b3301 Data Communication Error
failed in data expansion
There is a possibility of following errors
1. Communication Error
2. Data loss
Please contact the service when not repaired even if turns it on again.
4b3401 Nozzle check Error before Pickup(Detected before operating)
It stopped because the remains components on the nozzle or adhering matters
on the linear measure sensor of Light Emitter/Receiver were detected.
The remains Component on a nozzle or aw and soil on Light Emitter/Receiver of
Linear measure Sensor could be considered to adhere. Please clean it up.
4b3402 Nozzle check Error before Pickup(Detected before operating)
Error in Communication with Linear measure sensor.
Please conrm Error from Log Request Screen(Unit adjustment → Linear
measure Sensor Screen). Either, please conrm whether the items of LS-RLS-
S(Device Check → List) is Yellow. HLS communication cable could not be
connected and such like things.
4b3403 Nozzle check Error before Pickup(Detected before operating)
Error in Origin moving in HL/NL/L-axis
-----
4b3404 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up
-----
4b3405 Nozzle check Error before Pickup(Detected before operating)
Error in discarding the remains detect component
-----
4b3406 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up(program error)
-----
4b3501 Automatic Zeroing Error
Failed to zeroing automatically
Please restart.
4b3601 Receding Error
Motor Error on receding
-----
4b3602 Receding Error
Time-out on receding
-----
4b3701 Writing Origin position of License nozzle
Linear measure Sensor error is detected before operating.
-----
0911-001
4OM-1610
3-84
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3702 Writing Origin position of License nozzle
Failed in getting Offset data
-----
4b3703 Writing Origin position of License nozzle
Failing in writing origin position of Noz.
-----
4b3801 Bad Mark Sensor Error
Cannot detect Bad Mark normally for Error in Bad Mark Sensor.
Execute adjustment of Bad Mark Sensor
4b3901 Bad Mark Sensor Error
-----
4b3902 Bad Mark Sensor Error
-----
4b3903 Bad Mark Sensor Error
-----
4b3904 Bad Mark Sensor Error
-----
4b3905 Bad Mark Sensor Error
-----
4b3906 Bad Mark Sensor Error
-----
4b3907 Bad Mark Sensor Error
-----
4b3908 Bad Mark Sensor Error
-----
4b3909 Bad Mark Sensor Error
-----
4b390a Bad Mark Sensor Error
-----
4b390b Bad Mark Sensor Error
------
4b4001 Damaged cover tape / Cover tape jammed in the storage / Splicing section
peeling off
Alarm Code:E0 - (1)Damaged cover tape/ (2)Cover tape jammed in the storage/
(3)Splicing section peeling off
(1)Conrm whether or not the cover tape is set correctly/ (2) Please remove the
cover tape from the storage section./ (3) Please check the splicing condition if the
work performed correctly in the process.
4b4101 Cover tape peeling off error (Get caught up)
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
(1) Conrm whether or not the cover tape is set correctly./ (2)Conrm whether or
not some sticky material has adhered to the suppressor./ (3)Conrm the splicing
condition if the work performed correctly in the process.
0911-001
