4OM-1610
3-5
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
400416 Interlock Error
Over squeeze2 detected (Rear)[B05]
-----
400417 Interlock Error
Over squeeze3 detected (Rear)[B05]
-----
400418 Interlock Error
Pass level 1 error (Rear) detected[B04]
-----
400419 Interlock Error
Pass level 2 error (Rear) detected[B04]
-----
40041a Interlock Error
Pass level 3 error (Rear) detected[B04]
-----
40041b Interlock Error
Nozzle oat up 1 (Rear) detected[B1611]
Conrm Nozzle of Nozzle Stocker1(Rear).
40041c Interlock Error
Nozzle oat up 2 (Rear) detected[B1611]
Conrm Nozzle of Nozzle Stocker2(Rear).
40041d Interlock Error
Over squeeze1 detected (Front)[B05]
-----
40041e Interlock Error
Over squeeze2 detected (Front)[B05]
-----
40041f Interlock Error
Over squeeze3 detected (Front)[B05]
-----
400420 Interlock Error
Pass level 1 error (Front) detected[B04]
-----
400421 Interlock Error
Pass level 2 error (Front) detected[B04]
-----
400422 Interlock Error
Pass level 3 error (Front) detected[B04]
-----
400423 Interlock Error
Nozzle oat up 1 (Front) detected[B1611]
Conrm Nozzle of Nozzle Stocker1(Front).
400424 Interlock Error
Nozzle oat up 2 (Front) detected[B1611]
Conrm Nozzle of Nozzle Stocker2(Front).
4OM-1610
3-6
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
400425 Interlock Error
Emergency stop (Rear) detected
Drive after the power turns on.
400426 Interlock Error
Safety door (lower) of tray feeder unit opened.(Rear)[S0501]
Close the safety door(Lower) and operate it.
400427 Interlock Error
Safety door (upper) of tray feeder unit opened.(Rear)[S0502]
Close the safety door(Center) and operate it.
400428 Interlock Error
Safety door (center) of tray feeder unit opened.(Rear)[S0503]
Close the safety door(Upper) and operate it.
400429 Interlock Error
Chucking lever of pallet opened while elevator is moving.(Rear)[B15407, B15408]
Check out B15407, B15408, detection Sensor of closing Chucking lever of pallet.
40042a Interlock Error
Break out the pallet while elevator is moving.(Rear)[B15406]
Check out B15406(detecttion sensor of breaking out Pallet) and position of Pallet.
40042b Interlock Error
Detect pickup miss components on the pallet. (Rear)[B15417]
Please open the main cover and remove pickup miss components on the pallet.
40042c Interlock Error
Detect pickup miss components on the pallet. (Rear)[B15418]
Please open the main cover and remove the pickup miss components on tray
pallet.
40042d Interlock Error
Detect pickup miss components on the pallet. (Rear)[B15419]
Please open the main cover and remove the pickup miss components on tray
pallet.
40042e Interlock Error
Open the rack shutter while lower elevator is moving.(Rear)[B15521][B15523][B1
5525]
Check out B15521, B15523, B15525(the sensor of closing magazine rack
shutter).
40042f Interlock Error
Open the rack shutter while upper elevator is moving.(Rear)[B15527][B15529][B1
5531]
Check out B15527, B15529, B15531(the sensor of closing magazine rack
shutter).
400430 Interlock Error
Lower magazine positioning error.(Rear) [B15526]
Check Magazine Rack.
400431 Interlock Error
Upper magazine positioning error.(Rear) [B15532]
Check Magazine Clamp.
4OM-1610
3-7
3. Error IDs and Remedial Procedures : Chap.3
0911-001
Error ID Error Name, Description, Cause, and Remedy
400432 Interlock Error
Tripped circuit breaker of motor (Rear).
Please turn on again after turning off and cancelling Trip mode.
400433 Interlock Error
Cut off safety relay of lower elevator (Rear).
Check main circuit and safety door.
400434 Interlock Error
Cut off safety relay of upper elevator (Rear).
Check the main circuit and safety door.
400435 Interlock Error
Released clamp of elevator unit (Rear)[B15426, B15428]
Check out B15426, B15428(Elevator unit clamp sensor)
400436 Interlock Error
Detect pickup miss components (Rear) [B15412]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
400437 Interlock Error
Released Feeder Hook was detected(Rear)[B15412]
1.Open the cover.
2.Conrm suppressor, Disengaged Latch and remove the devices.
3.Close the cover and Lock it.
400438 Interlock Error
Emergency stop (Front) was detected
Please turn on the main body and operate it.
400439 Interlock Error
Safety door(Lower) of tray feeder unit opened.(Front)[S0501]
Please close the safety door(lower) and operate it.
40043a Interlock Error
Safety door(Upper) of tray feeder unit opened.(Front)[S0502]
Please close the safety door(upper) and operate it.
40043b Interlock Error
Safety door(Center) of tray feeder unit opened.(Front)[S0503]
Please close the safety door(center) and operate it.
40043c Interlock Error
Pallet Chuck Claw opened while elevator is moving.(Front)[B15407, B15408]
Check out B15407, B15408(detection Sensor of closing Chucking lever of pallet).
40043d Interlock Error
Pallet jutted out during elevator moving.(Front)[B15406]
Check out B15406(detecttion sensor of breaking out Pallet) and position of Pallet.
40043e Interlock Error
Pickup miss components on the Pallet was detected.(Front) [B15417]
Open the main cover and remove pickup miss components on the Tray Pallet.
40043f Interlock Error
Pickup miss components on the Pallet was detected.(Front) [B15418]
Open the main cover and remove pickup miss components on the Tray Pallet.
