4OM-1610
3-81
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3011 Cutter Error
Failed in reading the number of connection axes.
Please conrm AE-LINK wiring and Power wiring.
4b3012 Cutter Error
Communication status Error
Please conrm AE-LINK wiring and Power wiring.
4b3013 Cutter Error
Communication status Error(Stand by)
Please conrm AE-LINK wiring and Power wiring.
4b3014 Cutter Error
Communication Status Error(Alarm)
Please conrm the wiring of driver in Feeder Base unit
4b3015 Cutter Error
Communication Status Error(OT)
Please conrm the wiring of Origin Sensor.
4b3016 Cutter Error
Communication Status Error(Connection O)
Please conrm AE-LINK wiring and Power wiring.
4b3017 Cutter Error
Communication Status Error(Driver Alarm)
Please conrm the wiring of driver in Feeder Base unit
4b3018 Cutter Error
Communication Status Error(SV-NET stopping)
Please conrm AE-LINK wiring and Power wiring.
4b3019 Cutter Error
Communication Status Error(Out of Connection number)
Please conrm AE-LINK wiring and Power wiring.
4b301a Cutter Error
Communication Status Error(SV-NET Error)
Please conrm AE-LINK wiring and Power wiring.
4b301b Cutter Error
Cutter-axis is not connected.
Please conrm AE-LINK wiring and Power wiring.
4b301c Cutter Error
Failed to start-up Communication of SV-NET
Please conrm AE-LINK wiring and Power wiring.
4b3101 Cutter(Servo Error)
Error of Power Driver, Over-current
Check out motor wiring or exchange both motor and driver.
4b3102 Cutter(Servo Error)
Overload Alarm
Check out motor wiring or exchange both motor and driver. Either, Conrm that
the blocking exists with cutter pieces.
4b3103 Cutter(Servo Error)
Speed Alarm
Need to adjust motor gain again.
0911-001
4OM-1610
3-82
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3104 Cutter(Servo Error)
Multi-rotation Error
Check motor wiring or exchange motor.
4b3105 Cutter(Servo Error)
The value of Deviation Counter was over the set value
Check the wiring of Origin sensor. Either, Exchange driver.
4b3106 Cutter(Servo Error)
Power Drive detected temperature error.
Ambient Temperature is too high. Exchange driver.
4b3107 Cutter(Servo Error)
Sensor Error
Conrm the wiring of Motor Encoder. Either, exchange motor
4b3108 Cutter(Servo Error)
High Drive voltage
Insufcient power capacity. Exchange driver.
4b3109 Cutter(Servo Error)
Low drive voltage
Please conrm the operating Power wiring which is inserted to driver.
4b310a Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310b Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310c Cutter(Servo Error)
CPU Error
Exchange Driver
4b310d Cutter(Servo Error)
Parameter Error
Please conrm the changed Parameter
4b310e Cutter(Servo Error)
Alarm code readout failed
-----
4b3201 Servo Motor Error
Error of processing Servo On
-----
4b3202 Servo Motor Error
Time-out of processing Servo On
-----
4b3203 Servo Motor Error
Error of processing Servo Off
-----
4b3204 Servo Motor Error
Time-out of processing Servo Off
-----
0911-001
4OM-1610
3-83
3. Error IDs and Remedial Procedures : Chap.3
Error ID Error Name, Description, Cause, and Remedy
4b3205 Servo Motor Error
Time-out of processing Servo On(Rear)
Please restart the machine.
4b3206 Servo Motor Error
Time-out of processing Servo On(Front)
Please restart the machine.
4b3301 Data Communication Error
failed in data expansion
There is a possibility of following errors
1. Communication Error
2. Data loss
Please contact the service when not repaired even if turns it on again.
4b3401 Nozzle check Error before Pickup(Detected before operating)
It stopped because the remains components on the nozzle or adhering matters
on the linear measure sensor of Light Emitter/Receiver were detected.
The remains Component on a nozzle or aw and soil on Light Emitter/Receiver of
Linear measure Sensor could be considered to adhere. Please clean it up.
4b3402 Nozzle check Error before Pickup(Detected before operating)
Error in Communication with Linear measure sensor.
Please conrm Error from Log Request Screen(Unit adjustment → Linear
measure Sensor Screen). Either, please conrm whether the items of LS-RLS-
S(Device Check → List) is Yellow. HLS communication cable could not be
connected and such like things.
4b3403 Nozzle check Error before Pickup(Detected before operating)
Error in Origin moving in HL/NL/L-axis
-----
4b3404 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up
-----
4b3405 Nozzle check Error before Pickup(Detected before operating)
Error in discarding the remains detect component
-----
4b3406 Nozzle check Error before Pickup(Detected before operating)
Error of nozzle check before pick-up(program error)
-----
4b3501 Automatic Zeroing Error
Failed to zeroing automatically
Please restart.
4b3601 Receding Error
Motor Error on receding
-----
4b3602 Receding Error
Time-out on receding
-----
4b3701 Writing Origin position of License nozzle
Linear measure Sensor error is detected before operating.
-----
0911-001
