4OM-1610 2-14 3. Machine Information : Chap.2 Management Information Code Display Area A (The outline of the Management Information) Display Area B (The details of the Management Information) 050403 Manual transfer It is…
4OM-1610
2-13
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
030442 Operation Requirement
It cannot move because a simple Cover locked. First, set Stage ready OFF, then
set Stage ready ON.
030501 Misidentication a type of multi-tray
The connected Tray unit(Rear) doesn't match setup of Device. Please conrm a
type of tray unit, set it on unit exchange screen later.
030502 Misidentication a type of multi-tray
The connected Tray unit(Front) doesn't match setup of Device. Please conrm a
type of tray unit, set it on Unit Exchange Screen later.
030601 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Rear) on Unit exchange Screen.
030602 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
set the location of Noz stocker of Device(Front) on Unit exchange Screen.
030603 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Rear).
030604 Conrmation of the position of Noz Stocker
Cannot use Noz stocker from the second to the forth when full tray is used. Please
conrm the location of Noz stocker of Device(Front).
050201 Conrmation of P.C.B. existence
Remove P.C.B. from Conveyor
050202 Conrmation of P.C.B. existence
P.C.B. is detected from Input position because Finish mode is set [Output]. Please
P.C.B. from conveyor.
050203 Conrmation of P.C.B. existence
P.C.B. is detected from Output position because Finish mode is set [Input]. Please
P.C.B. from conveyor.
050204 Conrmation of P.C.B. existence
P.C.B. was detected from Inlet sensor of input conveyor. Please remove P.C.B.
050205 Conrmation of P.C.B. existence
The operation mode of Lane A is set [STOP]. Please remove P.C.B. when not
transferred.
050206 Conrmation of P.C.B. existence
The operation mode of Lane B is set [STOP]. Please remove P.C.B. when not
transferred.
050301 Conrmation of Firmware version
Firmware of transfer driver is not the latest version. Please update it with the latest
version.
050401 Manual transfer
P.C.B. (X>260mm) which is set by PP data is unable to take Input Position.
050402 Manual transfer
Please operate after removing P.C.B. from output conveyor. There is a possibility
of pushing and rising with Stopper.
0911-001
4OM-1610
2-14
3. Machine Information : Chap.2
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050403 Manual transfer
It is impossible to take from Sensor Detection of Input Position. Please put P.C.B.
on Input Conveyor, or move it to Output position in Recovery Menu.
050501 Convert Width Setup
Please set conveyor width 49.5 to 461.5mm. The total of P.C.B. size/offset/
clearance is over movable range.
050502 Convert Width Setup
Please set conveyor width 49.5 to 382.5mm. The total of P.C.B. size/offset/
clearance is over movable range.
050503 Convert Width Setup
Movable Range for the destination of W1 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050504 Convert Width Setup
Movable Range for the destination of W1 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050505 Convert Width Setup
Movable Range for the destination of W2 is set. Please check P.C.B. size/offset/
clearance of Lane A
050506 Convert Width Setup
Movable Range for the destination of W2 is set. Please check P.C.B. size/offset/
clearance of Lane A.
050507 Convert Width Setup
Movable Range for the destination of W3 is set. Please check P.C.B. size/offset/
clearance of Lane B.
050508 Convert Width Setup
Movable Range for the destination of W3 is set. Please check P.C.B. size/offset/
clearance of Lane B.
050509 Convert Width Setup
These is a possibility of the interference with W1 and W2. Please check P.C.B.
size/offset/clearance of Lane A.
05050a Convert Width Setup
There is a possibility of the interference with W2 and W3. Please Check P.C.B.
size/offset/clearance of Lane A/B.
050601 Middle Conveyor
Rotation Direction set of Middle Conveyor in supply side differs from Main Device
transfer direction. Please change the rotation direction of Middle conveyor.
050602 Middle Conveyor
Emergency Stop switch of middle conveyor in supply side is pressed. Please
cancel it.
050603 Middle Conveyor
Safety Cover of middle conveyor in supply side is open. Please close it.
050604 Middle Conveyor
Input Machine communication mode is set [PUSHER]. Cannot use [PUSHER]
mode when Middle Conveyor is contacted.
0911-001
4OM-1610
2-15
3. Machine Information : Chap.2
0911-001
Management
Information Code
Display Area A (The outline of the Management Information)
Display Area B (The details of the Management Information)
050611 Middle Conveyor
Rotation Direction set of Middle Conveyor in output side differs from Main Device
transfer direction. Please change the rotation direction of Middle conveyor.
050612 Middle Conveyor
Emergency Stop switch of middle conveyor in output side is pressed. Please
cancel it.
050613 Middle Conveyor
Safety Cover of middle conveyor in output side is open. Please close it.
060101 Feeder communication Error
Can not have communication with Feeder. Is Feeder selected Feeder No.
inserted?
060201 Feeder type Error
Library and Feeder are not the same.
060301 Feeder preparation Error
Make Feeder base dropped once. Then, rise it again.
060401 Feeder No. Error
The Feeder is not pickup. Please select another one.
060501 Nozzle Check
Nozzle is placed. Store it, and then execute.
060601 Cart Check
There is a possibility of Rear/Front of Cart missing. Please set cart normally.
060602 Cart Check
Cart(Rear) is not upper position. Please put it up.
060603 Cart Check
Cart(Front) is not upper position. Please put it up.
0d0c01 Pickup miss comp, Disengaged Latch Check
Please open the safety door. Are there no dropped pickup miss comp , no
disengaged Latch? Check them. If the comp was dropped, there is a possibility of
interference with Head.
0d0e01 Zeroing of Cutter is not completed
Execute All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve(Head in
the Rear side). Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve(Head in
the Front side). Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching
Tray's Pallet is not pulled out(Rear). Please pull it out.
0d0f04 Height Teaching
Tray's Pallet is not pulled out(Front). Please pull it out.
