Edition 2.0 NXT/NXT2 Repair Training Text
H12HS(Q) Hea
d
FK-9F98-61-0E 7-3 FUJI MACHINE MFG. CO., LTD.
Required Jigs and Grease:
Part name Part No. Component
Parts
Notes
Syringe insertion jig AA1XC0* - H12S head common use
Syringe pin extraction jig AA1WE0* - H12S head common use
H12HSθ-axis phase
alignment jig
AA6LH0*
PM6637* H12S head common use
PM07RA* Only for H12HS head
H12(S)/H12HS syringe
gear assembly 5.0 mm
torque spanner jig
AA6KK0*
PM9613* H12S head common use
CL3NX8D H12S head common use
H12HS syringe gear
assembly 5.0 mm
spanner
PB37510 - H12S head common use
H12HS syringe gear
assembly 4.0 mm
spanner
PB97690 - H12S head common use
Push-Pull gauge DPS-5 - H04, H08, H12S head common
use
Biral T&D Apply a small amount to the
syringe
MDV235-ZB Apply a small amount to the O-
ring in the syringe
Note: Some of the jigs are also used on other head types. Please be aware of this
when ordering jigs to avoid duplicating your order.
CONFIDENTIAL
SmartechMr.J FSun
Edition 2.0 NXT/NXT2 Repair Training Text
H12HS(Q) Hea
d
FK-9F98-61-0E 7-4 FUJI MACHINE MFG. CO., LTD.
1. Remove the following cover from the head.
2. Remove the collar and spring coil from all the syringes.
3. Remove the reference pin (thermal expansion mark) from the rotary holder.
CONFIDENTIAL
SmartechMr.J FSun
Edition 2.0 NXT/NXT2 Repair Training Text
H12HS(Q) Hea
d
FK-9F98-61-0E 7-5 FUJI MACHINE MFG. CO., LTD.
4. Remove the syringe pusher with the 5.0 mm spanner (PB 3751*) and 4.0 mm spanner
(PB9769*). Firstly, set the 5.0 mm spanner on the pusher as shown in the following
photo.
5. Next, set the 4.0 mm spanner (PB9769*) on the syringe as shown in the following
photo.
6. Fix the upper 5.0 mm spanner by hand and turn the lower 4.0 mm spanner clockwise
(as viewed from above the head) to remove the pusher.
7. Remove the syringe gear from the syringe.
Caution!
The H12HS syringe gear is a scissors gear. When removing the gear, be
careful not to lose the spring from between the gears.
PB97690
PB3751*
