Installation Manual, Station Software Version 705.03 02/2011 Edition
6 of 58
2 Scope of delivery
2.1 Software components
705.03 software
Standard package: 00140035-01 Software SIPLACE Station 705.03 Basic
- Software CD-ROM
(1)
- Software DVD SIPLACE Smart GUI
- License/product certificate
- Software Installation Manual V705.03 D+E (00196771-01)
- Packaging
Languages: 00140036-01 SIPLACE foreign language software SC 705.03
- CD-ROM with software (language pack)
- License/product certificate
- Software Version Description for foreign languages V705.03 D+E (00196772-01)
- Packaging
(1) The standard applications are contained on the CD:
- Embedded software for conveyor
- Embedded software for axes
- Embedded software for component tables
- Embedded software for tape cutter
- Embedded software for heads
- Embedded software for vision modules
- Embedded software for I/O modules
- Embedded software for X-feeders
- Embedded software for digital pressure regulation valve
- Embedded software for MTC2
- Embedded software for WPC5/WPC6
2.2 Hardware components
- Machine computer
- Vision computer (optional)
- Coplan computer (optional)
Installation Manual, Station Software Version 705.03 02/2011 Edition
7 of 58
2.3 Languages
SIPLACE Station and SIPLACE Vision GUI:
The standard package contains German and English versions.
Other languages are contained in the optional languages package and available under item number
00140036-01.
The following table indicates which languages are available for the station software and SIPLACE Vision:
Language
Station software /
SIPLACE Vision
French x
Italian x
Spanish (Mexico) x
Portuguese (Brazil) x
Czech
*)
x
Polish
*)
x
Hungarian x
Romanian
*)
x
Chinese (simplified) x
Korean x
Japanese x
*)
GUI only (online help English)
Installation Manual, Station Software Version 705.03 02/2011 Edition
3 Upgrading to the 705.03 software version
This chapter describes which steps you have to attend when upgrading from different software versions.
When upgrading the station software, always check the eSW versions and download the current versions if
necessary.
Note:
- With the installation of the 705.03 station software, statistic data (maintenance intervals) is
registered for the CPP and C&P20A placement heads and the SX main axis. In order to
achieve a defined initial state for the maintenance due, the correspondent maintenance
operations have to be performed on the subsystems after the software installation.
Note:
- An upgrade of the embedded software is necessary for the X-LDU. Generally, it is not
possible to perform a download of the embedded software via the station software for the X-
LDU. The X-LDU has to be upgraded to the 2.02 software version with the aid of an external
PC.
3.1 Upgrading from the 704.xx software version
→ Recalibrate the external cameras.
This is required, as the z height has been adapted for the dp calibration.
→ Save the calibration data for the placement heads (except Twin Head) in the EEPROM
(see section 7.9).
→ Perform a component sensor calibration if a CPP placement head is used for 0201/01005 placement.
3.2 Upgrading from the 703.02 or 703.02 SP1 software version
→ Please pay attention to the Technical Informations TI2010-10V02 and TI2010-10C02 when you
download the embedded software.
→ Recalibrate the travel ranges.
→ Recalibrate the external cameras.
This is required, as the z height has been adapted for the dp calibration.
→ SX-series placement machines in the field:
Due to the SW component counter, the HCU/GCU and the sensor modules have to be programmed.
For this, perform the work steps that are described in the Technical Informations TI2010-02V01 and
TI2010-02C01 about programming HCU/GCU for the 704 upgrade. These work steps can only be
performed by the SIPLACE Service.
