2.24 User Manual Software Version 7

The menu bar changes to the following:

NOTE

Restore default is only available while the highlighted directory is not already

at the default location.

Use the Next and Previous keys to move between the different directories.

Use the Exit key to close the File Locations window.

Use the Restore Default key to change the path, for files associated with the

highlighted directory, from the current location to the default location.

Selecting the Browse key opens the following window:

The menu bar changes to the following:

The message ‘Select a directory to become the current location for Process

Program files.’ is displayed in the message bar.

Use the Up and Down keys to scroll up and down the highlighted column.

Use the Left and Right keys to move between columns.

Use the Exit key to close the Directory Structure On Drive window.

Selecting the Create Dir key opens the following window:

The menu bar changes to the following:

Use the keyboard to type the name of the new directory.

Select the Proceed key, a new directory is created providing:

• The string entered constitutes a valid name for a directory.

• A file or directory of that name does not already exist.

• The current directory is accessible for writing.

Browse

Restore

Default

Next Previous Exit

Directory Structure On Drive

Current Directory Location

D:\Program Files\DEK\MachineControl\Printer

Select

Create

Dir

Left Right Up Down Exit

Create Directory

New Name:

Proceed Cancel

INFINITY

+267&20081,&$7,216

&200635272&2/237,216

Software Version 7 User Manual 3.1

CHAPTER 3 HOST COMMUNICATIONS

COMMS PROTOCOL OPTIONS

GEM This configuration implements the SMEMA standard for communications for

Surface Mount Equipment. GEM (Generic Equipment Model) is a standard sub-

set of the SECSII protocol. GEM is specifically designed for implementing

equipment automation in a production environment.

In this configuration, a host computer running GEM compatible software talks

to the machine via a Network cable.

If the Host is a PC, DEK’s Off-line editor software can be used to modify product

files. The Event Log can be read by a text editor. The flexibility of the GEM

interface allows data collection to be customized to meet the users requirements.

Net_Files This configuration allows users to redirect files away from the machines local

hard drive to a remote directory on a file server. The machine is configured to

access a ‘product’ directory for a product file and a ‘data’ directory for output

data files.

At the machine when a product file is loaded it is read from the ‘product’

directory on the network file server. When it is saved it is saved to the ‘product’

directory on the file server. Files cannot be read from the printer or sent to the

printer across the network.

Once the files are present on the server, they can be accessed from a networked

PC without interfering with the machine.

At a networked PC, DEK’s Off-line Editor software can be used to modify

product files. QC-Calc software can be used to access SPC data in the ‘READ-

INGS.DEK’ file. The Event Log can be read with a text editor.

Selecting Comms

Protocol Options

The Comms Protocol Set Preference SECS, GEM, and NET_FILE options each

display additional menu parameters if they are selected in the Set Preferences

window.

On selecting GEM the following menu bar is displayed:

On selecting NET_FILE the following menu bar is displayed:

If the Enable Comms key is pressed the following menu bar is displayed:

The user is given the option to Confirm or Exit their selection.

The NET_FILE option may cause a further window to appear requesting the

Network Password.

Enable

Comms

Next Previous Incr. Decr. Exit

Enable

Comms

Edit

Comms

Next Previous Incr. Decr. Exit

Confirm Exit

INFINITY

+267&20081,&$7,216

&200635272&2/237,216

3.2 User Manual Software Version 7

Editing NET_FILE

Comms Options

The NET_FILE comms editing window allows the user to change IP addresses,

user ID, file paths etc.

To enter the Edit Comms window from the set preferences window, select

NET_FILE from the Comms Protocol set preference and press the Edit Comms

menu bar option.

The Edit Comms window appears as follows:

To edit the Edit Comms window the following menu bar appears:

The Next and Previous keys are used to move the cursor up and down the

current column.

The Left and Right keys move the cursor between the two parameter columns.

The Edit keys makes the parameter under the cursor editable. When editing a

parameter the cursor keys and the delete keys can be used as well as the normal

alphanumeric keys. While editing a parameter (the cursor is still flashing),

pressing the Exit key finishes the current parameters editing.

The Exit key is used to leave the Edit Comms window.

Network Parameters

Remote Drive

User ID

Products Path

Data Path

Auto Login

Local Copies

Reconnect Period

Timeout

DISABLED

Edit Next Previous Left Right Exit
