INFINITY ',$*12 67, &6 35,17+($ ' Soft ware Ver sion 7 User Manual 5.9 PRINT HEAD Selecting this diagnostics module opens the following window: The menu bar changes displaying the following: Next / Previou…
INFINITY
',$*1267,&6
6<67(0
5.8 User Manual Software Version 7
The menu bar changes to the following:
Exit returns operation to the system diagnostics page.
Toggle Beacon Selecting any one of the three toggle beacon diagnostic functions, alternately
switches them between on and off.
Toggle Lid Bolt Selecting this function alternately extends and retracts the lid bolt.
Data Logging Selecting this diagnostic function alternately enables and disables data logging
during diagnostic operations.
Change Edit
Password
Selection of this option prompts the user to enter a new password.
Change
Diagnostics
Password
Selecting this diagnostic function either allows a password to be entered or
changes an existing password. This password protection inhibits unauthorized
entry into diagnostics.
Change Terminate
Password
Selecting this diagnostic function either allows a password to be entered or
changes an existing password. This password protection inhibits unauthorized
operation of the terminate control program.
Change Adjust
Password
Selecting this diagnostic function allows a password to be entered or changes an
existing password. This password protection inhibits unauthorized adjustments.
Change Fiducial
Set-up Password
Selecting this diagnostic function allows a password to be entered or changes an
existing password. This password protection inhibits unauthorized entry into the
fiducial setup.
Change
Maintenance
Password
Selecting this diagnostic function allows a password to be entered or changes an
existing password. This password protection inhibits unauthorized entry into the
maintenance functions.
Terminate Control
Program
Selecting this diagnostic function terminates the Infinity control program and
returns to Windows NT.
Exit
INFINITY
',$*1267,&6
35,17+($'
Software Version 7 User Manual 5.9
PRINT HEAD Selecting this diagnostics module opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Raise Head Under
2 Button Control
Selecting this diagnostic function allows the print head to be raised using the two
button control. These switches must be operated simultaneously.
Lower Head Under
2 Button Control
Selecting this diagnostic function allows the print head to be lowered using the
two button control. These switches must be operated simultaneously.
Toggle Head Latch Selecting this diagnostic function alternately switches the print head magnetic
latches on and off.
Toggle Lid Bolt Selecting this diagnostic function alternately extends and retracts the lid bolt.
Head Up Sensor This diagnostic function continuously displays the status of the head up sensor.
Head Down Sensor This diagnostic function continuously displays the status of the head down
sensor.
Lid Bolt Shut This diagnostic function continuously displays the status of the printhead lid bolt
sensor.
Head Prop Stowed This diagnostic function continuously displays the status of the head prop
stowed sensor.
Left Jog Button This diagnostic function continuously displays the status of the left jog button.
Right Jog Button This diagnostic function continuously displays the status of the right jog button.
Head Diagnostics
ON
Head Up Sensor
Head Down Sensor
Lid Bolt Shut
Head Prop Stowed
Left Jog Button
Right Jog Button
ON
Raise Head Under 2 Button Control
Lower Head Under 2 Button Control
Toggle Head Latch
Toggle Lid Bolt
ON
ON
ON
ON
ON
ON
Run
Diagnost
Next Previous Exit
INFINITY
',$*1267,&6
35,17&$55,$*(
5.10 User Manual Software Version 7
PRINT CARRIAGE
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of diagnostic
parameters.
Incr. / Decr. keys change the value of the selected diagnostic parameter.
Exit returns operation to the print carriage diagnostics page.
NOTE
These parameters are used in diagnostics only and have no affect on the product
board file.
Home Print
Carriage
Selecting this diagnostic function homes the print carriage, as set by its home
sensor. ‘Homing Print Carriage’ is displayed in the prompt box. It is always
advisable to home the print carriage before attempting to position it.
Print Carriage Diagnostics
Cycle Count
Done :-
0, To go :-
50
Home Print Carriage
Drive Carriage To Front Position
Drive Carriage To Paste Position
Drive Carriage To Rear Position
Drive Carriage Using Jog Buttons
Cycle Print Carriage
Run
Diagnost
Adjust Next Previous Exit
Print Carriage Diagnostic Parameters
FRONT PRINT SPEED
REAR PRINT SPEED
CYCLE COUNT
25
25
50.0
mm/s
mm/s
Cycles
Next Previous Incr. Decr. Exit
