INFINITY
',$*1267,&6
648((*((
5.14 User Manual Software Version 7
SQUEEGEE Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Home Front
Squeegee
Selecting this diagnostic function drives the front squeegee upwards to its home
position, as detected by its home sensor.
Home Rear
Squeegee
Selecting this diagnostic function drives the rear squeegee upwards to its home
position, as detected by its home sensor.
Front Squeegee to
Dwell Height
Selecting this diagnostic function drives the front squeegee to a position clear of
the top of the screen (default is 30mm).
Rear Squeegee to
Dwell Height
Selecting this diagnostic function drives the rear squeegee to a position clear of
the top of the screen (default is 30mm).
Rear Squeegee to
Flood Height
Selecting this diagnostic function drives the rear squeegee to the height set by
the flood reference height parameter.
Drive Front
Squeegee Using
Jog Buttons
Selecting this diagnostic function enables the front squeegee to be driven up and
down using the jog buttons. The right jog button drives the squeegee down and
the left jog button drives it up, stopping immediately the button is released. ‘Use
the Left Jog Button to move the Squeegee upwards, and the Right jog
Button to move it downwards.’ is displayed in the message prompt box.
Drive Rear
Squeegee Using
Jog Buttons
Selecting this diagnostic function enables the rear squeegee to be driven up and
down using the jog buttons. The right jog button drives the squeegee down and
the left jog button drives it up, stopping immediately the button is released. ‘Use
the Left Jog Button to move the Squeegee upwards, and the Right jog
Button to move it downwards.’ is displayed in the prompt box.
Squeegee Diagnostics
Pressure Reading
22.356
Home Front Squeegee
Home Rear Squeegee
Front Squeegee To Dwell Height
Rear Squeegee To Dwell Height
Rear Squeegee To Flood Height
Drive Front Squeegee Using Jog Buttons
Drive Rear Squeegee Using Jog Buttons
Run
Diagnost
Next Previous Exit
INFINITY
',$*1267,&6
648((*((
Software Version 7 User Manual 5.15
Pressure Reading This diagnostic function is a live display, showing the actual pressure being
applied to the squeegee. With no squeegees fitted the figure displayed varies
from machine to machine.
INFINITY
',$*1267,&6
&$0(5$$;(6
5.16 User Manual Software Version 7
CAMERA AXES Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Fiducial Setup enables screen fiducials to be located.
Adjust opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of diagnostic
parameters.
Incr. / Decr. keys change the value of the selected diagnostic parameter.
Exit returns operation to the camera diagnostics page.
NOTE
These parameters are used in diagnostics only and have no affect on the product
board file.
ON
ON
.. more
Home Camera X Axis
Home Camera YAxis
Camera Axis To Fiducial 1 Position
Camera Axis To Fiducial 2 Position
Camera Axis To Fiducial 3 Position
Drive to Board Stop Position
Restore Default Reference Position
Drive to Reference Position
Set Reference Position
Move Camera X Axis Using Jog Buttons
Move Camera YAxis Using Jog Buttons
Initialise Vision System
Fiducial Lighting
Inspection Lighting
Camera Diagnostics
Run
Diagnost
Adjust
Fiducial
Setup
Next Previous Exit
FIDUCIAL 1 X
FIDUCIAL 1 Y
FIDUCIAL 2 X
FIDUCIAL 2 Y
FIDUCIAL 3 X
FIDUCIAL 3 Y
BOARD STOP X
BOARD STOP Y
CYCLE COUNT
Camera Cycle Test Parameters
243.0
241.1
7.3
8.8
0.0
0.0
125.0
165.0
50.0
mm
mm
mm
mm
mm
mm
mm
mm
Cycles
Next Previous Incr. Decr. Exit
