INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
Software Version 7 User Manual 9.9
To Load Paste
During a Print Run
1. Press Paste Load (F3).
2. Press Auto Dispense (F1).
3. If the paste dispenser has sufficient paste the dispenser carries out an
automatic dispense, go to Step 22. If the paste dispenser is low on paste a
warning window is displayed. The warning window varies, depending on
the setting of the consumable action option in set preferences. If the set
preference is set to warn, continue with Step 4. If the set preference is set to
pause go to Step 10. If the set preference is set to suspend go to Step 16.
4. If the set preference is set to warn, the tricoloured beacon shows amber/green
and the following window is displayed:
5. Select Confirm (F1).
6. Select End Run (F1).
7. To replace the paste cartridge carry out Fitting a New Paste Cartridge
procedure, later in this section.
8. Select Run (F1).
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
Warning
Print Medium Low. Please replenish.
Confirm
End
Run
Stop
Cycle
Paste
Load
Clean
Screen
Adjust
Knead
Paste
Run Head
Paste
Load
Clean
Screen
Adjust Setup Monitor Maint.
INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
9.10 User Manual Software Version 7
If the Camera Idle Position in Set Preferences is set to Behind Rail, the
following window and menu bar is displayed:
Selecting Continue Run clears the warning window and the print cycle
continues.
Selecting End Run clears the warning window, the print cycle is aborted and
control is returned to the ready page.
If the Unload Board Start in Set Preferences is set to Separation, the follow-
ing window and menu bar is displayed:
Selecting Continue Run clears the warning window and the print cycle
continues.
Selecting End Run clears the warning window, the print cycle is aborted and
control is returned to the ready page.
NOTE
If Camera Idle Position is set to Behind Rail and Unload Board Start is set
to Separation, the warning windows appear one after the other in the order
shown above.
9. Repeat Steps 1, 2 and 22.
Camera Behind Rail Warning
The CAMERA HOME POSITION is set to 'Behind
Rail'
Ensure that no tooling pins or other
obstructions are on the table behind the
rear rail, as these could cause damage to
the camera.
This option will only have an effect for
boards that are less than 250mm wide.
This option can be disabled from the set
preference page.
Continue
Run
End
Run
Unload Board Speedup Warning
The UNLOAD BOARD SPEEDUP option is set to
'Separation'
With this option enabled it should be noted
that there is only a minimal clearance
between the underside of the board and any
tooling being used, while the board is being
unloaded.
This option must not be used for boards that
are populated on the underside, as this
could damage the boards.
Continue
Run
End
Run
INFINITY
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
Software Version 7 User Manual 9.11
10.If the set preference is set to pause, the tricoloured beacon shows red and the
following window is displayed:
11. Select Refill Paste (F1). The message ‘Select Load Cart to load the
cartridge or exit to abort.’ is displayed.
NOTE
Select Defer to continue printing without replacing the paste cartridge.
12.Select Load Cart. (F1). The message ‘Open the cover and load the new
paste cartridge then close Cover, press System Button and press Con-
tinue’ is displayed.
13.Carry out Steps 3-9 of Fitting a New Paste Cartridge procedure, later in this
section.
14.Select Continue (F1).
15.Go to Step 21.
16.If the set preference is set to suspend, the tricoloured beacon shows red and
the following window is displayed:
17.Select Refill Paste (F1). The message ‘Select Load Cart to load the
cartridge or exit to abort.’ is displayed.
NOTE
Select End Run to terminate the print run without replacing the paste
cartridge.
Pause on Warning
Print Medium Low. Please replenish.
Refill
Paste
Defer
Load
Cart.
Exit
Continue
Open
Cover
Suspend on Warning
Print Medium Low. Please replenish.
Refill
Paste
End
Run
