INFINITY
(55250(66$*(6
(55250(66$*(/,67,1*
Software Version 7 User Manual 4.5
Command Timed Out
(Front/Rear Squeegee)
This error reports that the front/rear squeegee has failed to move to the
demanded position within the time period. Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Downline Board Transfer Fault This error reports that the time the downline interface has waited for a
board has exceeded the time-out.
Downline Machine Not Available This error reports that the downline machine is unavailable to accept the
next board.
Dual Shuttle Fault This error reports that the 20 seconds time-out period has been exceeded
when loading or unloading a screen.
Event File Open Error This error reports that there was a problem opening the event log backup
file.
Failed to Determine Tooling Deviation This error reports that while monitoring the tooling deviation, the number
of samples (pressure variations) during the print stroke was less than 2 or
the minimum value was zero. This error message is only valid where
tooling deviation is authorized and enabled.
Check tooling support is sufficient.
Check underside components are clear of tooling.
Front Squeegee Error This error reports that the front squeegee has failed to reach its fully up
position.
Front Squeegee Pressure Error When this error is detected a new window displays the set pressure reading
and the actual pressure reading.
File Error This message appears if there is an error writing or reading a machine file.
Have All Tooling Pins Been Removed? This message appears for the user to confirm that all magnetic tooling pins
have been removed, before setting up the machine for a new board file that
uses AutoFlex tooling.
Invalid Calibration Data. Recalibrate
ProFlow Heights
This error reports that the ProFlow calibration data is corrupt or invalid.
Invalid Calibration Data. Recalibrate
Squeegee Heights
This error reports that the squeegee calibration data is corrupt or invalid.
Lid Bolt Fault This indicates that the lid bolt has failed to either open or close.
No Paste Knead Cycles Selected This error reports when Knead Paste is selected on main menu page and
Knead Deposits in Set Prefs is selected to 0 cycles.
Paste Carriage Error This error reports that the paste carriage has failed to reach its home
position.
Paste Cartridge Tilt Error This error reports that the paste cartridge mechanism has failed to either
make its up or down limit switches.
Pneumatic Power Down This error message reports that the pneumatic supply is either too low or
has been disconnected.
Position Error (Camera This error reports that the cameras actual position is not within the
tolerance of 1% of the designated position.
Position Error (Print Carriage) This error reports the print carriage actual position is not within tolerance
of its designated position.
Position Error (Rising Table) This error reports that the rising table has failed to reach its home position.
Error Message Interpretation
INFINITY
(55250(66$*(6
(55250(66$*(/,67,1*
4.6 User Manual Software Version 7
Position Error
(Screen Load)
This error reports that a problem has occurred while unloading the screen.
Possible causes are:
Motor fault
Sensor fault
Print Carriage Error This error reports that the print carriage has failed to move.
Proflow Downstop At Limit This error reports when the downstop reaches set limits whilst using the
jog buttons in Diagnostics, Drive Downstop Using Jog Buttons.
Proflow at Movement Limit This error reports when the proflow reaches set limits whilst using jog
buttons in Diagnostics, Drive System Using Jog Buttons.
Rail Lifted Error, Check Tooling This error reports that either the left rail lifted sensor or the right rail lifted
sensor are out of their home positions when any of the following moves
are taking place:
Alignment of the screen
Board stop moving into position
Initialization of the machine
Initialization of the AutoFlex tooling
Possible causes are:
A misfed board
Tooling/object on the rising table striking the underside of the rails
Rear Squeegee Error This error reports that the rear squeegee failed to reach its fully up position.
Rear Squeegee Pressure Error When this error is detected a new window displays the set pressure reading
and the actual pressure reading.
Rising Table Error This error reports that the rising table has either failed to reach its fully
down position or that when attempting to reach the required height during
the machine cycle did not achieve the positional accuracy.
Rising Table Out of Position This error reports that either; the camera axes are not at the home position
when the rising table is to be lifted, or the rising table is at a height greater
than vision height by 1mm.
Screen/Board Fiducial Not Found This error reports that the vision system has been unable to locate the
screen/board fiducial (n). Possible causes are:
Incorrect board file for the product being run.
Incorrect board loaded.
Correct board loaded the wrong way up.
Screen Changer Drive Error This error indicates that no screen movement has been detected when the
screen changer is attempting to move the screen either at initialization or
at a screen change request.
Screen Cleaner Out Of Position This error reports that the screen cleaner is out of position. Possible causes
are:
Screen Cleaner not at the home position.
Home sensor - enter Diagnostics, Digital Inputs and check the sensor
changes state.
If a screen cleaner is not fitted, check that the home sensor is not con-
nected.
Screen Couplings Not Extended This error reports that the screen couplings have failed to extend within
the 4 second time-out period.
Screen Fiducial Not Found This error reports that the vision system has been unable to locate the
screen fiducial.
Screen XF Error This error reports that the X forward screen actuator failed to initialize to
its central datum.
Error Message Interpretation
INFINITY
(55250(66$*(6
(55250(66$*(/,67,1*
Software Version 7 User Manual 4.7
Screen XR Error This error reports that the X rear screen actuator failed to initialize to its
central datum.
Screen Y Error This error reports that the Y screen actuator failed to initialize to its central
datum.
Set Pressure %2.21f Actual Pressure %2.21f
(Front/Rear Squeegee)
This error reports if the front/rear squeegee pressure differs from the
pressure set by more than ± 1.00Kg.
Stop After Idle Time Exceeded This error reports if the idle time is exceeded, the options to continue or
abort are displayed. Continue resets the idle timer or abort allows for
Manual or Auto unload.
System Power Down This error reports that the 24V motor power has been switched off either
by the Emergency Stop button being activated (including upline and
downline external machines) or that the removable frame access cover has
been removed.
System Suspended While Covers Open This error reports that whilst the machine was switched on, one or more
of the cover interlock switches were out of position.
Table Movement Inhibited,
Camera Not Home.
This error reports that the camera is over the table and the NextMove is
sent an instruction to move the rising table.
This Diagnostic Cannot Run
Until Proflow Is At home
This error reports if proflow is not in the home position (Print Carriage
Diagnostics only).
This Diagnostic Cannot Run With Proflow
Fitted
This error reports if in Print Carriage Diagnostics, Move Print Carriage to
Paste Position is selected.
Unable to Find Fiducial This error reports that the vision system is unable to locate the relevant
screen or board fiducial.
Upline Board Transfer Error This indicates that there is a problem in loading a board from the upline
machine.
Upline Machine Not Available This error reports that the upline machine is unavailable to accept the next
board.
Window Error This error reports that the menu structure has failed to open correctly.
X Actuator Limit Exceeded This error reports that either X actuators are driven past its limit set during
calibration.
Y Actuator Limit Exceeded This error reports that the Y actuator is driven past its limit set during
calibration.
Error Message Interpretation
