Appendix
Description of Boards 4.1.4 Vision board spread spectrum HCU [03067289-xx]
74 Gantry Exchange Portaltausch
Dip switch S1 [03067289-02]
4.1.4.1
4.1.4.1 DIP Switch on the Vision Board (Digital Version 02)
DIP Switch on the Vision Board (Digital Version 02)
* Not all gantries may be available, depending on the machine type.
D20 GN ON P3.3VCAM + 3.3VDC for camera
D23 GN ON P5V +5VDC
D25 GN ON P15V +15VDC
Switch Status Signal name Description
S1.1 OFF HW_RESET ON: RESET CAN controller
S1.2 OFF CAN_ID Not used
LED Color Status Signal name Description
S Gantry* Comments
1 2 3 4
1 OFF OFF OFF OFF Reset - CAN processor
2 OFF ON OFF ON PID0 address switch 1 -> gan-
try
3OFF OFF ON ONPID1 address switch 2 -> gan-
try
4 OFF OFF OFF OFF CAN R - switch for the terminal
resistor on the CAN bus
5ON ONON ONSpeed: ON = 1 Mbit/s, OFF =
500 Kbit/s
6ON ONON ONCAN ID - for X machine ON
acpage
