4OM-1505 2-50 2. T roubleshooting on Each Section : Chap.2 0906-001 T4B47 Error ID Error Name, Description, Cause, and Remedy 1802038 PEC Recog. #2 Unavailable ducial mark polality was set. 1802040 PEC Recog. #2 Unavail…
4OM-1505
2-49
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B46
Error ID Error Name, Description, Cause, and Remedy
1801038 PEC Recog. #1
Unavailable ducial mark polality was set.
1801040 PEC Recog. #1
Unavailable ducial mark area was set.
1801043 PEC Recog. #1
Recognition system error.
1801056 PEC Recog. #1
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1802000 PEC Recog. #2
1802001 PEC Recog. #2
[Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1802003 PEC Recog. #2
[Camera Gain] exceeds the range of setting.
1802004
PEC Recog. #2
[Camera Level] exceeds the range of setting.
1802011 PEC Recog. #2
[Mark Size D1] exceeds the range of setting.
1802012 PEC Recog. #2
[Mark Size D2] exceeds the range of setting.
1802014 PEC Recog. #2
[Mark Judge Level] exceeds the range of setting.
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1802029 PEC Recog. #2
Image around ducial mark was unstable.
1802030 PEC Recog. #2
Error of mark gure similitude was extensive.
1802031 PEC Recog. #2
Error of mark similitude or mark size was extensive.
1802032
PEC Recog. #2
Specied mark was not found in window of recog.monitor.
(Cause 1) The ducial marks do not conform to the coordinates X and Y of the ducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
"Error ID "1801032"" for details.
4OM-1505
2-50
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B47
Error ID Error Name, Description, Cause, and Remedy
1802038 PEC Recog. #2
Unavailable ducial mark polality was set.
1802040 PEC Recog. #2
Unavailable ducial mark area was set.
1802043 PEC Recog. #2
Recognition system error.
1802056 PEC Recog. #2
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1804000 PEC Recog. T
est
1804001 PEC Recog. Test
[Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1804003 PEC Recog.
Test
[Camera Gain] exceeds the range of setting.
1804004 PEC Recog. Test
[Camera Level] exceeds the range of setting.
1804011 PEC Recog. Test
[Mark Size D1] exceeds the range of setting.
1804012 PEC Recog. Test
[Mark Size D2] exceeds the range of setting.
1804014 PEC Recog. Test
[Mark Judge Level] exceeds the range of setting.
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1804029 PEC Recog. Test
Image around ducial mark was unstable.
1804030
PEC Recog. Test
Error of mark gure similitude was extensive.
1804031 PEC Recog. Test
Error of mark similitude or mark size was extensive.
1804032 PEC Recog. Test
Specied mark was not found in window of recog.monitor.
(Cause 1) The ducial marks do not conform to the coordinates X and Y of the ducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
"Error ID "1801032"" for details.
4OM-1505
2-51
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B48
Error ID Error Name, Description, Cause, and Remedy
1804038 PEC Recog. Test
Unavailable ducial mark polality was set.
1804040 PEC Recog. Test
Unavailable ducial mark area was set.
1804043 PEC Recog. Test
Recognition system error.
1804056 PEC Recog. Test
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1806000 PEC Recog. Camera
1806001 PEC Recog. Camera
[Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1806003 PEC Recog. Camera
[Camera Gain] exceeds the range of setting.
1806004
PEC Recog. Camera
[Camera Level] exceeds the range of setting.
1806011 PEC Recog. Camera
[Mark Size D1] exceeds the range of setting.
1806012 PEC Recog. Camera
[Mark Size D2] exceeds the range of setting.
1806014 PEC Recog. Camera
[Mark Judge Level] exceeds the range of setting.
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1806029 PEC Recog. Camera
Image around ducial mark was unstable.
1806030 PEC Recog. Camera
Error of mark gure similitude was extensive.
1806031 PEC Recog. Camera
Error of mark similitude or mark size was extensive.
1806032
PEC Recog. Camera
Specied mark was not found in window of recog.monitor.
(Cause 1) The ducial marks do not conform to the coordinates X and Y of the ducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
"Error ID "1801032"" for details.
