4OM-1505
2-64
2. Troubleshooting on Each Section : Chap.2
(22 Others)
T4B61
Error ID Error Name, Description, Cause, and Remedy
2201000 Vacuum Blower Motor.
Vacuum sw was not ON, within specied time.
(Cause 1) The vacuum jig is not used.
(Cause 2) Vacuum Leakage
(Cause 3) The vacuum switch is defective.
(Remedy 1) When the vacuum jig is not used, specify the vacuum jig in the pattern
program.
(Remedy 2) Check for vacuum leakage between the PCB and the vacuum jig.
(Remedy 3) The vacuum switch might be set incorrectly or the main body of the vacuum
switch might be defective. Contact our service personnel for details.
2202000
Vacuum Blower Motor.
Cleaning side change timeover
(Cause 1) The suction changeover cylinder might be malfunctioning or the cylinder sensor
might be defective.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
2203000
Vacuum Blower Motor.
V
acuum plate side change timeover.
(Cause 1) The suction changeover cylinder might be malfunctioning or the cylinder sensor
might be defective.
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
0906-001
4OM-1505
2-65
2. Troubleshooting on Each Section : Chap.2
0907-002
(23 Backup Pin Setup)
T4B62
Error ID Error Name, Description, Cause, and Remedy
2501000 Backup Pin Setup
A pin does not stand on the specied position.
Pin No. : XX
(Cause 1) In the Pin Presence/Absence check, there is no pin on the specied position.
(Remedy 1) Return all the pins to the stock area by hand and repeat the procedure from
the beginning.
2502000 Backup Pin Auto Setup
The backup pin automatic setup failed. Pin No. : XX
(Cause 1)
During the automatic setup, the pin pick-up or placement failed.
(Remedy 1) According to the instructions on the window, return the pin to the specied
stocker and repeat the setup procedure from the beginning.
When the same error still occurs, contact our service personnel for details.
2503000 Backup Pin
Auto Setup
Pin Chuck Section UP/DOWN Cylinder Malfunction
(Cause 1) All the pins are not set correctly in the stocker or on the table.
(Cause 2) Cylinder sensor positional deviation or error
(Remedy 1) Conrm that the pin where a pick-up error occurred has been set correctly
and the pin end is not bent.
(Remedy 2) Move the chuck section up and down and conrm that the sensor reacts
correctly.
2504000
Backup Pin Auto Setup
Pin Chuck Section Chuck Cylinder Malfunction
(Cause 1)
Error in Pick-up Conrmation Sensor
(Remedy 1) According to the instructions on the window, return the pin to the specied
stocker and repeat the setup procedure from the beginning.
When the same error still occurs, contact our service personnel for details.
2512000 Backup Pin Auto Setup
The conveyor is not opened. Execute the [W
ork Position Move] procedure.
(Cause 1) The table chute is not fully opened.
(Remedy 1) After executing the [Work Position Move] procedure, repeat the procedure.
2513000 Backup Pin Auto Setup
During the operation to return the pins to the stocker, there were some undetected pins.
Pin No. : XX
(Cause 1)
Not all the pins are set correctly on the table.
(Remedy 1) Conrm that there is no pin left on the table and all the pins are housed in the
stocker.
2515000 Backup Pin
Auto Setup
Backup pin pick-up conrmation failed.
(Cause 1) All the pins are not set correctly in the stocker or on the table.
(Cause 2) Error in Pick-up Conrmation Sensor
(Cause 3) Vacuum Head Height Error
(Remedy 1) Conrm that there are no pins dropped on the table or in the stocker.
(Remedy 2)
Return the pins to the stocker and repeat the setup operation.
(Remedy 3) When the same error still occurs, contact our service personnel for details.
