4OM-1505 1-5 1. Outline of Maintenance : Chap.1 Specied Tools for Lubrication (1) Brush Use a brush whose bristles do not come off if possible. Notice Do not use a brush for ball screws and splines. (2) Vinyl Gloves Use…
4OM-1505
1-4
1. Outline of Maintenance : Chap.1
1.2.2 Preparation for Lubrication
Prepare for the specied types of grease and lubrication tools.
Specied Greases
•
DAPHNE EPONEX GREASE No. 1 (IDEMITSU KOSA
N)
•
MOLYNOC GREASE
AP1 (NIPPON OIL CORPORATION)
Note
(a) Before lubrication, wipe off old grease. Otherwise, the effect of grease and
oil will decrease.
(b) Obtain the material safety data sheet (MSDS) from the maker to learn the
precautionary points on handling and check the contents described in detail
for correct use.
Same Types of Lubricants
•
Lubricants equivalent to DAPHNE EPONEX GREASE No. 1 (IDEMITSU
KOSAN)
Grease Names Makers
Alvania Grease No. 1 Showa Shell Sekiyu K.K
Multinoc Grease No. 1 NIPPON OIL CORPORATION
Jomo Lisonix Grease No. 1 JAPAN ENERGY CORPORATION
Dynamax No. 1 COSMO OIL LUBRICANTS
Lithtan 1 ESSO OIL
MP Grease No. 1 KYGNUS
Gemico MP-1 Tonen General Sekiyu K.K
Multemp PS1 KYODOH YUSHI CO., LTD.
T4A3
•
Lubricants equivalent to MOLYNOC Grease AP1 (NIPPON OIL
CORPORATION)
Grease Names Makers
DAPHNE Grease M No. 1 IDEMITSU KOSAN
Jomo Lisonix Grease M-No. 1 JAPAN ENERGY CORPORATION
Jomo Lisonix Grease M-No. 1 COSMO OIL LUBRICANTS
BEACON Q2 ESSO OIL
Gemico MD2 TonenGeneral Sekiyu K.K.
M5 GREASE 1 KYGNUS
T4A4
0906-001
4OM-1505
1-5
1. Outline of Maintenance : Chap.1
Specied Tools for Lubrication
(1) Brush
Use a brush whose bristles do not come off if possible.
Notice
Do not use a brush for ball screws and splines.
(2) Vinyl Gloves
Use a pair of vinyl gloves to apply grease or oil by hand.
(3) Hand Grease Gun
Standard : KH-120
Part No : 228A0022
Maker : Yamada Corporation
Note
Use this gun only for DAPHNE EPONEX GREASE No. 1.
Reference
Refer to the attached instruction manual of the hand grease gun for the
usage.
F4A2
•
Attachments for Hand Grease Gun KH-120
Standard Shape Part No. Remarks
P Type
216M0441 THK
H Type
216M0439 THK
U Type
216M0438 THK
SPK-3C
228A0021
Yamada
Corporation
T4A5
Note
It is not attached to the machine. Purchase it separately if necessary.
1002-002
4OM-1505
1-6
1. Outline of Maintenance : Chap.1
1.3 Items for Periodic Maintenance
The items (inspection, cleaning, lubrication, etc.) that require periodic
maintenance are classied and described based on each individual devices.
Reference
Refer to "2. Maintenance Check List" for the maintenance based on frequency
of use.
Notice
The * -marks represent that the items require maintenance only for the
rst time.
Follow the
-marked maintenance cycle for the subsequent use.
Device Name
Inspection, Cleaning, and
Lubricating Spots
Work
Maintenance Cycle
Daily
Weekly
Monthly
Every 3
Months
Every 6
Months
5 Years
3.2.1
Air Source
Drain Cleaning
3.2.2
Squeegee Head Section
Squeegeee Cleaning
Recognition Lighting Glass
Surface
Cleaning
Squeegeee Head
Y-Axis Linear Guide
(Left Side), (Right Side)
Cleaning
Lubrication
Stencil Recognition
X-Axis Linear Guide
Cleaning
Lubrication
Guide Bushing for Squeegee
Up/Down Movement
Cleaning
Lubrication
Squeegee Head Y-Axis Ball
Screw
Lubrication
Stencil Recognition X-Axis
Ball Screw
Lubrication
3.2.3
Stencil Holder Section
Stencil Printing Pattern Cleaning
Upper Surface of Stencil
Holder
Cleaning
Lower Surface of Stencil Cleaning
Stencil Y-Axis Linear Guide
(Front Side), (Rear Side)
Cleaning
Lubrication
Stencil Y-Axis Ball Screw
Lubrication
