Brief description Required Working Time 2.5.3 Reje ct Box / Nozzle Station IC Camer a [03112806-xx] 66 Stationary Camera Type 25/33 Stationäre Kamera Typ 25/ 33

100%1 / 94
Brief description
2.5.3 Reject Box / Nozzle Station IC Camera [03112806-xx] Tools and Equipment Required
Stationary Camera Type 25/33 Stationäre Kamera Typ 25/33 65
2.5.3
2.5.3 Reject Box / Nozzle Station IC Camera [03112806-xx]
Reject Box / Nozzle Station IC Camera [03112806-xx]
2.6
2.6 Tools and Equipment Required
Tools and Equipment Required
▪ Standard tools
▪ Sliding gauge
▪ Shortened Allen key size 5, if required
▪ Microfiber cloth for cleaning optical assemblies, if required
2.7
2.7 Required Working Time
Required Working Time
The complete installation will take approx. 1.5 hours.
Quanti
-
ty
Designation Item No.
1 Connecting plate 03113448-xx
1 Holder reject box 03117361-xx
1 Reject box large, complete 03106815-xx
1 Sensor assembly IC camera 03115381-xx
3 Shim plate for nozzle reject device 03104733-xx
1 Support for nozzle reject device 03104731-xx
1 Nozzle station CPx complete / X4iS, XS 03090348-xx
2 ISO 7380-2 M 3 x 6-A2-70 03099571-xx
2 ISO10642 - M5 x 10-A2-70 03082832-xx
2 ISO 7046-2-M3 x 6-A2-70-H 03023238-xx
2 DIN7984-M6x12-A2-70 03081847-xx
Brief description
Required Working Time 2.5.3 Reject Box / Nozzle Station IC Camera [03112806-xx]
66 Stationary Camera Type 25/33 Stationäre Kamera Typ 25/33
Installation
Stationary Camera Type 25/33 Stationäre Kamera Typ 25/33 67
3
3 Installation
Installation
CAUTION - Do not hold or ca rry the cam era by its e lectronics unit.
CAUTION - Crash danger - Observe the installation height of the cameras
CAUTION
Do not hold or carry the camera by its electronics unit.
The camera electronics assembly is a sensitive unit and can be easily damaged.
► Only hold or carry the camera by its metal frame.
► Always pull the illumination unit carefully up and off.
► The metal housing must always be hooked out of the lower section of the camera.
CAUTION
Crash danger
When fitting the camera, make sure that you observe the correct installation height, otherwise
this could create a risk of head crash.
